FSN IPS4000 - Timing

31
11/2022
Standard Input Signal Table
Standard Output Signal Table
Resolution
Timing Information Signal Source
H-Freq (KHz) V-Freq (Hz) Clock (MHz) HDMI DP SDI (12G) CVBS RGB
1920 x 1080p@50 56.25 50.00 148.500 ••• •
1920 x 1080p@59 67.43 59.94 148.352 ••• •
1920 x 1080p@60 67.50 60.00 148.500 ••• •
1920 x 2160 133.29 59.99 277.250 •••
3840 x 2160 67.50 30.00 297.00 •••
3840 x 2160 112.50 50.00 594.00 •••
3840 x 2160 134.87 59.94 593.41 •••
3840 x 2160 135.00 60.00 594.00 •••
4096 x 2160 67.50 30.00 297.00 ••
4096 x 2160 112.50 50.00 594.00 ••
4096 x 2160 134.87 59.94 593.41 ••
4096 x 2160 135.00 60.00 594.00 ••
Resolution
Timing Information Signal Source
H-Freq (KHz) V-Freq (Hz) Clock (MHz) HDMI DP SDI (12G)
1920 x 1080p@50 56.25 50.00 148.500 •••
1920 x 1080p@60 67.50 60.00 148.500 •••
3840 x 2160@50 112.50 50.00 594.00 •••
3840 x 2160@60 135.00 60.00 594.00 •••
