28
10/2021
Input/Output Timing IPS710A
Resolution
Horizontal
Frequency (KHz)
Vertical Frequency (Hz) Clock Frequency (MHz)
720 X 400 @70Hz 31.50 70.00 28.32
640 X 480 @60Hz 31.50 60.00 25.17
640 X 480 @75Hz 37.50 75.00 31.50
800 X 600 @60Hz 37.90 60.00 40.00
800 X 600 @75Hz 46.90 60.00 49.50
1024 X 768 @60Hz 48.40 60.00 65.00
1024 X 768 @75Hz 60.00 75.00 78.75
1280 X 1024@60Hz 64.00 60.00 108.00
1280 X 1024@75Hz 80.00 75.00 135.00
1360 X 768@60Hz 47.72 60.00 84.75
480p 31.50 60.00 27.03
720p 45.00 60.00 74.25
1080i 33.75 60.00 74.25
1080p 67.50 60.00 148.50
1920 x 1200@60Hz 74.12 60.00 154.25
DVI input
CVBS input
SDI input/output
Signal in Description
Video NTSC / PAL
Signal in / out Description
SMPTE-424M 1080p
SMPTE-292M 720p / 1080i
SMPTE-259M 480i / 576i
Power Consumption IPS710A
Mode Consumption (W), Max < 30
Rear AC Switch O 0
Standby (Soft Power O ) < 5
Normal Operation (Live View) < 20
Recording with Capture (USB Multi-recording) < 25
Data Backup (External Storage with USB Power) < 30
