General Speci cation IPS740 series
Item Description
Main
Functions
Video recording Up to 3840 x 2160p 60Hz
Still image capture Up to 3840 x 2160
Standalone preview Front LCD screen
Menu access Front LCD touchscreen, or GUI on HDMI monitor output
DICOM, HL7
DICOM store (image & video), Modality worklist,
MPPS, Appointment booking (HL7)
DICOM store Direct access to PACS
Inputs
HDMI HDMI 2.0
DisplayPort DP 1.4
SDI IPS740DS: 3G-SDI, IPS740DG: 12G-SDI, 2SI, Quad
Audio 3.5mm stereo x 2ea , Mic in, Line in
Outputs
Monitor output HDMI 2.0
Loop-through IPS740DS: 3G-SDI, IPS740DG: 12G-SDI, 2SI, Quad
Audio 3.5mm Stereo line out
Data I/O
USB3.0 Front: 2, Rear: 2
RS-232C Mini-USB
Ethernet RJ45 ( 10/100/1000M )
Keyboard / Mouse USB type
Foot pedal
3.5mm stereo jack x 2ea, Record, Capture
Recording &
Capture
Recording resolution 1920x1080p60, 3840x2160p60
Encoding formats H.264, H.265
Recording  le format MP4
Capture image format BMP, JPEG, DICOM
Audio encoding format AAC
3D video formats
4K line alternative (SBSH conversion)
4K side-by-side half
Storage
Internal hard drive 4TB
External USB storage
USB  ash drive, USB HDD
USB  le system FAT32, NTFS
Network  le system CIFS
Network transfer FTP (client)
General
Power requirements AC 100-240V ~, 50-60Hz, 1.0A-0.6A MAX
Power consumption 60W MAX
Dimensions
260mm (10.2 in.) wide x 95mm (3.7 in.) high x 330mm (13 in.) deep
Weight IPS740DS 4.0kg / 8.8lbs., IPS740DG 4.1kg / 9.0lbs.
Temperature
Operating: 0° to +40° C (+32° to +104° F)
Storage: -20° to + 60° C (-4° to +140° F)
Humidity Operating: 10 - 85% RH, Storage: 10 - 85% RH
Compliance and
Certi cations
CE-MDD 93/42/EEC Class 1 Medical Device, UL 60601-1, IEC60601-1, EN 60601-1-2, FCC Part 15B,
CCC, ISO9001, ISO13485, RoHS
