Input/Output Timing IPS740 series
HDMI input
Resolution Horizontal Frequency (KHz) Vertical Frequency (Hz) Clock Frequency (MHz)
640 x 480 31.47 59.94 25.173
800 x 600 37.88 60.32 40.00
1024 x 768 48.36 60.00 65.00
1280 x 720 44.76 60.00 74.486
1280 x 1024 63.98 60.02 108.50
1920 x 1200 74.04 59.95 154.00
720p 45.00 60.00 74.25
1080i 33.75 60.00 74.25
1080p 67.50 60.00 148.50
3840 x 2160p 135.00 60.00 594.00
4096 x 2160p 135.00 60.00 594.00
HDMI output
Resolution Horizontal Frequency (KHz) Vertical Frequency (Hz) Clock Frequency (MHz)
1920 X 1080@60Hz 67.5 60.0 148.5
3840 X 2160@60Hz 135.0 60.0 594.0
DisplayPort input
Resolution Horizontal Frequency (KHz) Vertical Frequency (Hz) Clock Frequency (MHz)
1080p 67.50 60.00 148.50
3840 x 2160p 135.00 60.00 594.00
4096 x 2160p 135.00 60.00 594.00
SDI input
Signal input Description
SMPTE ST-2082 2160p
SMPTE-424M 1080p
SMPTE-292M 1080i / 720p
SMPTE-259M 480i / 576i
SDI loop through output
Signal input Description
SMPTE ST-2082 2160p
SMPTE-424M 1080p
SMPTE-292M 1080i / 720p
SMPTE-259M 480i / 576i
