11
FRAME PIVOT SPECIFICATIONS
B = Blue Loctite required
Part#
1.a
1.b
1.c
1.d
1.e
1.f
1.g
1.h
1.k
1.m
Qty
2
4
2
4
2
2
1
6
2
6
Part Description
BB Bearing
Dropout Bearing
S- Link @ Frame Bearing
S- Link @ Seatstay Bearing
S-Link @ Clevis Bearing
BB Bearing Spacer
BB Shell Middle Spacer
Dropout Bearing Spacer
S-Link @ Frame Bearing Spacer
S-Link @ Seatstay Bearing Spacer
Part Specification
6902 2RS Series Bearing - 28mm O.D. x 15mm I.D. x 7mm Thick
6800-2RS Series Bearing - 19mm O.D. x 10mm I.D. x 5mm Thick
6805 2RS Series Bearing - 37mm O.D. x 25mm I.D. x 7mm Thick
6800-2RS Series Bearing - 19mm O.D. x 10mm I.D. x 5mm Thick
608 Series Bearing - 22mm O.D. x 8mm I.D. x 7mm Thick
Alloy spacer - 20mm O.D. x 15mm I.D. x 3mm Thick, Chamfered
Alloy Bushing - 19mm O.D. x 15mm I.D. x 33.5mm Thick
Alloy spacer - 16mm O.D. x 10mm I.D. x 2mm Thick, Chamfered
Alloy spacer - 32mm O.D. x 25mm I.D. x 3mm Thick, Chamfered
Alloy spacer - 16mm O.D. x 10mm I.D. x 2mm Thick, Chamfered
Part#
2.a
2.b
2.c
2.d
2.e
2.f
2.g
2.h
2.k
2.m
2.n
2.o
2.p
2.q
2.r
Qty
1
1
2
2
2
1
2
2
2
2
2
1
1
1
2
Part Description
BB Axle
BB Nut
Dropout Axle
Dropout Bolt
Dropout Bolt Hat
S- Link @ Frame Eccentric Sleeve
S- Link @ Frame Bolt
S- Link @ Seatstay Axle
S- Link @ Seatstay Bolt
S- Link @ Seatstay Bolt Hat
S-Link @ Clevis Bolt
Lower (Rearward) Shock Eye Bolt
Upper (Forward) Shock Eye Bolt
Upper (Forward) Shock Eye Nut
Upper (Forward) Shock Eye Washer
Part Specification
Alloy Axle - M15 Thread (21mm Head O.D.) x 70mm Shaft Length, 8mm Hex
Alloy Nut - M15 Thread x 23.5mm O.D, 19mm socket
(use 6-point socket only)
Alloy Axle - M6 I.D. Thread x 10mm O.D. x 22mm Shaft Length, 4mm Hex
Steel Bolt - M6 Thread x 15mm Shaft Length, 5mm Hex
Alloy Hat Washer - 16mm O.D. x 6mm I.D. x 4.5mm Thick
Alloy Sleeve - M15 Internal Threaded Eccentric Bore x 25mm O.D. x 69mm Length
Alloy Bolt - M15 Thread x 34mm Shaft Length, 8mm Countersunk Hex
Alloy Axle - M6 I.D. Thread x 10mm O.D. x 22mm Shaft Length, 4mm Hex
Steel Bolt - M6 Thread x 15mm Shaft Length, 5mm Hex
Alloy Hat Washer - 16mm O.D. x 6mm I.D. x 4.5mm Thick
Steel Bolt - M8 Thread x 16mm Shaft Length, 5mm Hex
Alloy Bolt - M15 Thread x 28mm Shaft Length, 8mm Hex
Steel Bolt - M8 Thread x 45mm Shaft Length, 6mm Hex
Steel Nut - M8 Thread x 8mm Thick, 13mm Open Wrench
Steel Washer - 14mm O.D. x 8.5mm I.D. x 1mm Thick
Torque in*lb
200-230 B
200-230
100-120
100-120 B
200-230 B
100-120
100-120 B
120-140 B
200-230 B
180-200 B
180-200
