FRAME GEOMETRY
1. Top Tube Length
1
4. Seat Tube Angle
2
7. Standover Height
3
10. Reach
2. Chainstay Length 5. Head Tube Angle 8. Head Tube Length
3. BB Height 6. Wheelbase 9. Stack
9
1
5
4
3
6
2
10
7
250mm
8
1
TT length is the Horizontal Measurement from the center-line of the HT at the top of the
HT to the center-line of the projected seat tube.
2
Effective Seat Tube Angle is measured from BB to 250mm above seat collar.
3
Stand Over height is measured vertically at the centerpoint of the TT measurement.
Headset: 1 1/8” top, 1.5” bottom Derailleur Hanger: 9895-4020
Seatpost diameter: 30.9mm SX Trail Eye to Eye: 216mm (8.5”)
Front derailleur clamp: E-Type Direct Mount (DMD) SX Trail Shock Stroke: 63.5mm (2.5”)
Seat Collar: 34.9mm SX Eye to Eye: 190.5mm (7.5”)
Rear hub spacing: 135mm SX Shock Stroke: 38.1mm (1.5”)
BB shell: 73mm
