Paper Jams
111
Troubleshooting
6
3
Remove the jammed paper.
Note • If the paper is torn, make sure no piece of
paper remains inside the machine.
4
If paper is jammed in the fusing unit, move the
lever A1 towards you to open the chute of the
fusing unit.
5
Remove the jammed paper.
Important • The fusing unit is extremely hot. Do not touch
the fusing unit as it may result in burn injury.
Note • If the paper is torn, make sure no piece of
paper remains inside the machine.
6
Return the lever A1 to the original position, and close the chute of the fusing unit.
7
Push the center of the top left cover and close the cover gently.
Paper Jams in Center Tray Exit
1
While lifting up the release lever (1), gently
open the top left cover (2).
îš„When the Side Tray (optional) is installed
Remove paper from the Side Tray (1), close the
Side Tray (2), and then open the top left cover.
To Next Page
