Appendix
814
Appendix
16
îš„ Document: Auto, Coordinate Origin: 0 degrees, Scaling Mode: Paper Size, Scaling: On
z
Change the factory default setting if required. For more information on changing procedures, refer to "HP-
GL/2 Emulation" (P.812).
Paper Margin
The paper size is set to A series paper by factory default. If the print data is larger than the
active coordinates area, the machine prints the data on the next larger A series paper (for
example, the next larger size of A4 is A3).
When you set the paper margins, however, the active coordinates area is determined by
subtracting the area set in paper margins from the active coordinates area obtained in the
area determination mode. Therefore, set the paper margins if the data is printed on larger
paper than specified. Set the range from 0 to 99 mm. The default value is 0 mm.
HP-GL/2 Emulation Settings
The following table shows the emulation parameters and their values for HP-GL/2
emulation.
HP-GL/2 Settings List
Items that can be set using the HP-GL/2 mode menu are explained in two groups: basic
settings and extended settings.
Document Size
Paper Size
Print Area
To Next Page
