5
*1
Refer to the tables below for actual site space requirements for each available configuration
*2
Rear service clearance is measured from the wall to the back of the IOT (not the Integrated Fiery Server if fitted).
. Installation of an Oversize High Capacity Feeder; Finisher D3 w/booklet & folder or Finisher D4 results in a Non-Moveable
installation.
Minimum overhead clearance for all installations (Measured from floor to ceiling) = 2,000 mm (H). Actual machine height
is 1,423mm.
NOTE: If an External Print Server is connected, an additional 91.5cm x 91.5cm square site area is required outside of the
machine space requirements
TIP: when using the below table refer to the configuration of your device, working from left (feeder) to right (finisher)
IOT without HCF
Configuration
Min. Site Space (mm)
Comment
(refer to site diagram for
dimensions required)
Site Width
Depth (with
Integrated Fiery)
IOT + Catch Tray
2372
2123
Movable Installation
IOT + C3 Finisher
2802
2123
Movable Installation
IOT + C3 Finisher (with Booklet Maker)
2861
2123
Movable Installation
IOT + C3 Finisher (with Booklet Maker & folder)
3332
2483
Non-Movable Installation
IOT + IFM + D4 Finisher (+ Booklet Maker)
3357
2483
Non-Movable Installation
IOT + IFM + D4 Finisher (+ Booklet Maker) + Square Fold Trimmer
4139
2483
Non-Movable Installation
IOT + IFM + D4 Finisher (+ Booklet Maker) + GBC AdvancedPunch
3662
2483
Non-Movable Installation
IOT + IFM + D4 Finisher (+ Booklet Maker) + GBC AdvancedPunch +
Square Fold Trimmer
4444
2483
Non-Movable Installation
IOT + IFM + D4 Finisher (with Booklet Maker & Folder Unit)
3557
2483
Non-Movable Installation
IOT + IFM + D4 Finisher (with Booklet Maker & Folder Unit) + Square
Fold Trimmer
4339
2483
Non-Movable Installation
IOT + IFM + D4 Finisher (with Booklet Maker & Folder Unit) + GBC
AdvancedPunch
3862
2483
Non-Movable Installation
IOT + IFM + D4 Finisher (with Booklet Maker & Folder Unit) + GBC
AdvancedPunch + Square Fold Trimmer
4644
2483
Non-Movable Installation
IOT with A4 HCF
Configuration
Min. Site Space (mm)
Comment
Site Width
Depth (with
Integrated Fiery)
IOT + A4 High Capacity Feeder (HCF) + Catch Tray
2452
2123
Movable Installation
IOT + A4 High Capacity Feeder (HCF) + C3 Finisher
2882
2483
Non-Movable Installation
IOT + A4 High Capacity Feeder (HCF) + C3 Finisher (with Booklet
Maker)
2941
2483
Non-Movable Installation
IOT + A4 High Capacity Feeder (HCF) + C3 Finisher (with Booklet Maker
& folder)
3412
2483
Non-Movable Installation
IOT + A4 High Capacity Feeder (HCF) + IFM + D4 Finisher (+ Booklet
Maker)
3437
2483
Non-Movable Installation
IOT + A4 High Capacity Feeder (HCF) + IFM + D4 Finisher (+ Booklet
Maker) + Square Fold Trimmer
4219
2483
Non-Movable Installation
IOT + A4 High Capacity Feeder (HCF) + IFM + D4 Finisher (+ Booklet
Maker) + GBC AdvancedPunch
3742
2483
Non-Movable Installation
IOT + A4 High Capacity Feeder (HCF) + IFM + D4 Finisher (+ Booklet
Maker) + GBC AdvancedPunch + Square Fold Trimmer
4524
2483
Non-Movable Installation
