15 Appendix
570
Appendix
15
*2 For the center binding/folding feature, Booklet Maker Unit for Finisher-B1 is required. After a job
with center binding/folding specified was output, remove the output paper from the tray to output the
next job. In addition, when you print a job with center binding/folding specified and smaller-sized
paper remains on the output tray, remove the paper from the tray first.
*3 For the Punching feature, US 2/3 Hole Punch Kit for Finisher-B1 or 2/4 Hole Punch Kit for Finisher-
B1 is required.
îš„ Finisher-C1 (optional)
Type Output tray × 1: Sorting/Stacking
Finisher tray × 1: Sorting (Offset available)/
Stacking (Offset available)
Paper Size/Paper
Weight
Output tray Maximum: 12.6 × 17.7", 12 × 19",
Minimum: B5, 55 - 220 gsm
Finisher tray Maximum: 12.6 × 17.7", 12 × 19",
Minimum: B5, 55 - 220 gsm
Stacker Capacity Output tray 500 sheets (A4)
Finisher tray (For paper not stapled)
A4: 3,000 sheets
B4 or larger: 1,500 sheets
Mixed stack*: 300 sheets
Finisher tray (For paper stapled)
A4: 200 sets or 3,000 sheets
B4 or larger: 100 sets or 1,500 sheets
* Based on when larger size paper is stacked on paper.
Important • When using 80 gsm paper
Staple Capacity: 50 sheets (90 gsm
or less)
Paper Size: Maximum: A3, 11 × 17", Minimum: B5
Position: 1 place (front/back, angled stapling),
2 places (parallel stapling)
Important • When using 80 gsm paper
Punch Paper size: A3, 11 × 17", B4, A4, A4 , 8.5 × 11",
8.5 × 11" , B5
Number of Holes: 2/4 holes (Option: US 2/3 holes)
Paper Weight: 55 - 220 gsm
Important • When using 80 gsm paper
Dimensions/Weight Width 817 × Depth 639 × Height 1,058mm, 60 kg
Space Requirement
(when connected to the
main unit)
Width 1,863 × Depth 685 mm (Main unit + Finisher-C1, when the
extension tray and the bypass tray are fully extended)
