Mainboard D2264
Installing/removing or replacing main memory
Technical data
Technology: DDR2 400 / DDR2 533 / DDR2 667 and DDR2 800 unbuffered DIMM modules
240-Pin; 1.8 V; 64 Bit, without ECC
Size: 64 Mbytes to 8 Gbyte DDR
Granularity: 64, 128, 256, 512, 1024 or 2048 Mbyte for one socket
A current list of the memory modules recommended for this mainboard is available on the Internet
at:
www.fujitsu-siemens.com/mainboards.
At least one memory module must be installed. Memory modules with different memory capacities
can be combined.
!
You may use only unbuffered 1.8 V memory modules without ECC.
DDR2 memory modules must meet the PC2-3200U- or PC2-4200U- or PC2-5300U- or
PC2-6400U-specification.
i
If you use more than one memory module, then make sure to distribute the memory
modules over both memory channels. By doing this you use the performance advantages
of the dual-channel mode.
The maximum system performance is given when the same memory size is used in
Channel A and Channel B.
To simplify equipping, the slots are colour coded.
When inserting the memory modules start with the slot located the furthest away from the
processor (slot 4).
With a memory configuration of 4 Gbytes the visible and usable main memory can be
reduced down to 3.5 Gbytes (depending on the system configuration).
More than 4 GByte main memory can only be used with a corresponding operating
system.
2
4
A
3
1
A
B
B
Slot Channel
Number of inserted memory modules
slot to be used 1 2 3 4
Channel A, slot 1 X
Channel B, slot 2 X X
Channel A, slot 3 X X X
Channel B, slot 4 X X X X
The installation/removal is described in the "Basic information on mainboard" manual.
4 - English A26361-D2264-Z110-1-7419, edition 2
