Mainboard D2264
Multifunctional expansion cards or expansion cards with integrated PCI-PCI bridge
These expansion cards require up to four PCI interrupts: INT A, INT B, INT C, INT D. How many and
which of these interrupts are used is specified in the documentation provided with the card.
The assignment of the PCI interrupts to the IRQ Lines is shown in the following table:
Controller or slot INT
Mechanical slot
On board controller
1 2 3 4 - - -
PCI Slot
PCI
INT
LINE
USB 1.1
USB 2.0
IDE
SATA 0/1
HD Audio
LAN
VGA
PCIe x16
PCIe x1
1 2 - - -
1 (A)
X
- - X X - - - - B A - - -
2 (B)
-
X - - - - - - - A B - - -
3 (C)
-
- - - - - - - - D C - - -
4 (D)
-
- - - - X - - - C D - - -
5 (E)
-
- - - - - - - - - - - -
6 (F)
-
- - - - - - - - - - - -
7 (G)
-
- - - - - - - - - - - -
8 (H)
-
- - - - - - - - - - - -
ID
SEL
- - - - - - - - - 21 23 - - -
Dev# 0Bh 0Bh 0Dh 0Eh/0Fh 10h 14h 05h 02h 03h 05h 07h - - -
Func
tion#
0 1 0 0 1 0 0 0 0 0 0 - - -
Bus# 0 0 0 0 0 0 0 0 0 4 4 - - -
* with onboard Grafic
Use first PCI/PCI Express slots that have a single PCI IRQ Line (no IRQ sharing). If you must use
another PCI/PCI Express slot with IRQ sharing, check whether the expansion card properly supports
IRQ sharing with the other devices on this PCI IRQ Line. The drivers of all cards and components on
this PCI IRQ Line must also support IRQ sharing.
6 - English A26361-D2264-Z110-1-7419, edition 2
