Brief description of mainbo ard
Mechanical slo t
PCI INT LINE
1(A) 2(B) 3(C) 4(D) 5(E) 6(F) 7(G) 8(H)
PCI
Slot 1
-
DA
-
B
C
--
Slot 2
-
A
-
B
C
D
--
Slot 6
--
BCDA
--
PCIe x16
AB
C
D
----
PCIe x16
AB
C
D
----
PCIe x1
------
x
-
PCIe x4
AB
C
D
----
Use first PCI/PCI Express slots that have a single PCI IRQ Line (no IRQ sharing). If you
must use another PCI/PCI Express slot with IRQ sharing, check whether the expansion card
properly supports IRQ sharing with the other devices on this PCI IRQ Line. The drivers of all
cards and components on this PCI IRQ Line must also support IR Q sharing.
6 - English A26361-D2764-Z 110-1-7419, edition 1
