21.5" wide LCD Monitor
Edition 2
Technical data
Dimensions and weight (LCD monitor)
Visible diagonals: 54 cm (21.5” wide)
Screen size : 476.64mm x 268.11mm
Dimensions (W x H x D) incl. monitor base : 509.5 mm x 402.3 mm x 214.9mm
Dimensions box (W x H x D): 556 mm x 364 mm x 116 mm
Weight : 4 kg/5.4kg
Dot pitch : 0.248 mm
Maximal resolution : 1920 x 1080 pixels
Electrical data
Video: analogue, positive, 0.7 Vpp, 75 Ohm,
Synchronisation : Separate H/V-sync
Horizontal frequency: 28kHz …. 82kHz
Refresh rate: 56 Hz ….75 Hz
Maximum pixel rate: 190 MHz
Power supply: 100 VAC - 240VAC，50Hz - 60Hz, 1.2 A max.
Total power consumption: < 50 W (active)
< 1 W (stand by)
Environmental conditions
Environment class 3K2, IEC 721
Operating range: 5 °C .... 35 °C
Humidity: 15 % ... 85 %
Condensation must be avoided.
Preset operating modes
The picture position and size have been set set to optimum values at the factory for the
operating modes listed above.
Display resolution Refresh rate Horizontal frequency
640 x 480
640 x 480
720 x 400
800 x 600
800 x 600
1024 x768
1024 x 768
1280x1024
1440 x 900
1680x1050
1920x1080
60 Hz
75 Hz
70 Hz
60 Hz
75 Hz
60 Hz
75 Hz
60 Hz
60 Hz
60 Hz
60 Hz
31.5 kHz
37.5 kHz
31.5 kHz
37.9 kHz
46.9 kHz
48.4 kHz
60 kHz
64 kHz
59.9 kHz
64.7 kHz
67.2 kHz
