To Next PageTo Next PageHow to fix U401-DATA output issues on Fujitsu Siemens Computers FSC B15-1A?
If the U401-DATA output is faulty on your Fujitsu Siemens Computers Monitor, consider replacing the MST8011B (U401) or PA0~PA9, PB0~PB9. Alternatively, you may need to replace the MAINBOARD.
How to troubleshoot Inverter Control Relative Circuit problems in Fujitsu Siemens Computers FSC B15-1A Monitor?
To address issues with the Inverter Control Relative Circuit in your Fujitsu Siemens Computers Monitor, you can replace U401MST8011 or replace the power board. Also, check if the screen is working normally.
What to do if I have PANEL-POWER CIRCUIT issue in Fujitsu Siemens Computers Monitor?
If you are experiencing issues with the panel-power circuit in your Fujitsu Siemens Computers Monitor, replacing Q203 might resolve the problem.
Basic setup and connection guidelines for the monitor.
Description of monitor control buttons and indicators.
Step-by-step guide for OSD picture adjustments.
Details of the analog D-SUB input connector pinout.
List of supported horizontal frequencies and resolutions.
Electrical specifications for the monitor's power input.
Electrical specifications for the monitor's power output.
Key characteristics and features of the LCD panel.
Technical display properties like resolution and pixel pitch.
Measured optical performance parameters of the panel.
Visual representation of monitor components and their assembly.
Block diagram for the main control board.
Block diagram for the power supply and backlight inverter.
Detailed circuit diagram for the main board.
Detailed circuit diagram for the inverter and power board.
Detailed circuit diagram for the keypad interface board.
Physical layout of the main circuit board's components.
Physical layout of the inverter/power board's components.
Physical layout of the keypad board's components.
List of necessary tools and equipment for maintenance.
Diagnostic steps and solutions for common monitor issues.
Basic setup and connection guidelines for the monitor.
Description of monitor control buttons and indicators.
Step-by-step guide for OSD picture adjustments.
Details of the analog D-SUB input connector pinout.
List of supported horizontal frequencies and resolutions.
Electrical specifications for the monitor's power input.
Electrical specifications for the monitor's power output.
Key characteristics and features of the LCD panel.
Technical display properties like resolution and pixel pitch.
Measured optical performance parameters of the panel.
Visual representation of monitor components and their assembly.
Block diagram for the main control board.
Block diagram for the power supply and backlight inverter.
Detailed circuit diagram for the main board.
Detailed circuit diagram for the inverter and power board.
Detailed circuit diagram for the keypad interface board.
Physical layout of the main circuit board's components.
Physical layout of the inverter/power board's components.
Physical layout of the keypad board's components.
List of necessary tools and equipment for maintenance.
Diagnostic steps and solutions for common monitor issues.
General| Screen Size | 15 inches |
|---|---|
| Display Type | TFT LCD |
| Resolution | 1024 x 768 pixels |
| Aspect Ratio | 4:3 |
| Brightness | 250 cd/m² |
| Contrast Ratio | 400:1 |
| Input Connectors | VGA |
| Weight | 3.5 kg |
| Viewing Angle | 140° horizontal / 120° vertical |
| Power Consumption | 30 W |
