– 17 –
When you order parts, please make a photocopy of this page
and fill the number of the parts in the “Order” column.
INDOOR UNIT
PARTS LIST
Ref.
No.
Description Q’ty
3 Louver 9358561010
8-1 Air Filter 9358567012
34 Capacitor (Fan Motor) 9357965017
2.3µF/450V
36-2 Cord Holder Metal 9356362008
56 Sirocco Fan Assy 9358621004
67 Rubber (Vibration-proof) 313659068604
68 Cap, Plastic 9358563007
108 Base Assy 9359061014
109 Casing, Plastic 9358543009
124 Dew Proof Plate 9359196006
126 Motor Fixing Table Assy 9358591000
127 Drain Hose Assy 9359242000
138 Separate Wall-A 9358584002
146 Evaporator Assy C688E 9358870013
160 Drain Pan Assy 9358568002
164 Fan Motor Assy-In MFA-24CTA 9600364031
173 Hanger Bracket-L 9358596005
174 Hanger Bracket-R 9358595008
184-1 Thermistor Spring-A 313728262708
187 Clamp No. 1219 313361271706
195 Clamp SKB-100 313361275805
196-1 Clamp SKB-3M 312300787605
210
Main Relay JM1AN-ZTM-DC12V 9356781007
211 Cushion Rubber 313806328306
223 Control Box 9358600016
234 Thermistor Assy-Room 9703299025
235 Thermistor Assy-Pipe 9701102068
236 Controller PCB Assy 9701941094
EZ-096VWSE-C
240 Remote Control Unit AR-DL2 9359913023
320 Flap (Upper)-F 9358538012
321 Flap (Lower) 9358541012
329 Coupling Pipe Assy 9358819005
338 Motor Fixture 9358594001
361 Bushing 9357942001
361-2 Bushing-B, Plastic 9358554005
361-3 Bushing-C, Plastic 9358553008
365-1 Special Screw 9359092001
365-2 Special Screw 9359091004
381 Locking Spacer, KGLS-4S 313209391506
385 Indicator PCB Assy 9701873012
EZ-0964HSE-D
407 Motor Rod 9358560006
408 Louver Link 9358556009
416 Insulation (Panel)-A 9358574003
417 Insulation (Panel)-B 9358914007
418 Insulation (Flap Base) 9358572009
422 Clamp NK-10N 9359183006
439 Drain Pan Wire 9358598009
443 Arm Bracket 9359281009
470 Separate Wall-B 9358585009
Part No.
ABY24AGB–W
Ref.
No.
Description Q’ty
472 Grille Support 9358602003
473 Filter Bracket 9358607008
488 Grille-F 9358532010
500 Protect Cover 9358564004
502 Support Stay 9358599006
503 Louver Shaft 9358557006
505 Louver Stopper 9358555002
506 Louver Rod 9358559000
508 Cosmetic Panel-R 9358535011
509 Cosmetic Panel-L 9358536018
514 Control Box Cover 9359097006
520 Flap Base 9358537015
521 Louver Link Cover 9358558003
552 Insulation (Eva.)-R 9358575000
553 Insulation (Eva.)-L 9358857007
554 Flap Link-Upper (Step Motor-V) 9358551004
555 Flap Link-Lower (Step Motor-V) 9358552001
558 Motor Rod-A (Step Motor-V) 9358550007
574-1 Evaporator Fixture-R (Bracket) 9358589007
574-2 Evaporator Fixture-L (Bracket) 9358590003
577 Catch TL-119 9359096009
578 Base Bracket 9358586006
(Reinforcement Metal)
580 Top Cover 9358534014
581 Protector, Metal (For Motor) 9359282006
588-1 Evaporator Bracket-R 9358587003
588-2 Evaporator Bracket-L 9358588000
625 Cord Bushing KR-51 9359240006
628 Locking Spacer-B 313005446558
629 EMI Filter 0400197119
652-1 Thermistor Holder Pipe 313806262805
653-1 Bolt (Fan Motor Fixing) 0700156014
653-2 Bolt 0700190018
684 Motor Base 9358562000
689 Screw, Grip Tapping 9357837000
SN+4016 ZNY, w/Grip
731-2 Holder (Guide Rail) 0600241018
735 Distributor Assy 9358814000
743 Remote Control Unit Holder 9359955016
755 Casing Cover 9358544006
764 Drain Cap 9358746004
771 Panel Assy “FUJITSU” 9359076018
815-1 Terminal-3P 9358660041
824-3 Fuse BET 3.15A-250V 0600222512
868 PCB Holder 9358547007
870-1 Arm 9358565001
870-2 Center Arm 9359280002
875 Filter PCB Assy 9702081010
EZ-0964HSE-P
876-1 Step Motor-H 9359106012
876-2 Step Motor-V 9359105015
923 Control Box Bracket 9358717004
Part No.
Ref.
No.
Description Q’ty
772 Joint Pipe-A 9302812021
Part No.
OPTIONAL PARTS FOR INDOOR UNIT
