– 19 –
ABY24AGB–W
When you order parts, please make a photocopy of this page
and fill the number of the parts in the “Order” column.
Ref. No. Ref. No.Description Description
Ord.
Q’ty
Ord.
Q’ty
IC1 IC µPD78014HCW-013 9702426026
IC2 IC NJM7812FA 0100462104
IC3 IC NJM7805FA 0100462081
IC4~6 Xstr µPA2003GR 0100028041
IC7 IC NM82C46M8-X 0101622026
IC8 IC PST600CMTR 0101461120
IC9 Photocoupler TLP621(D4)-GB 0000117074
Q1 Xstr 2SC4236 0000164047
Q2 Xstr 2SC1740S 0000699235
Q3,4 Xstr DTC124EK 0000936033
D1 Diode D3SB60 0000689045
D2,4,7 Diode D1FL20U 0000746519
D3 Diode MTZJ5.1B 0000852166
D5 Diode 1SR139-600 0000353120
D6 Diode D2FL20U 0000906500
D8 Diode D1F60 0000208024
D9 Diode DA226U 0000625036
D12 Diode DAN202K 0000684019
R1 Res. Cement 5W 3.3Ω±5% 0200244372
R2 Res. Metal 2W 1.5Ω±5% 0201107119
R3 Res. 1/10W 100Ω±5% 0200212500
R4 Res. Carbon 1W 220kΩ±5% 0200111353
R5 Res. Metal 2W 47kΩ±5% 0201107652
R6 Res. 1/2W 100Ω±5% 0200731506
R7 Res. 1/4W 330Ω±5% 0200708621
R8,10,13, Res. 1/10W 330Ω±5% 0200213019
15~17,21~24,
29~32,37,
39,48,50,
52,53,55,
59,68
R9,47 Res. 1/10W 390Ω±5% 0200212647
R11 Res. Metal 1W 56kΩ±5% 0201106662
R12,18~20, Res. 1/10W 1kΩ±5% 0200212746
25~28,
33~36,
38,42,44,
46,49,51,
56~58,67
R40,41 Res. 1/10W 4.7kΩ±5% 0200212906
R43 Res. 1/10W 10kΩ±5% 0200279497
R45 Res. 1/10W 49.9kΩ±5% 0200279824
R54 Res. 1/10W 47Ω±5% 0200212425
CJ1,2 Res. 0Ω 0200212012
C5 Cap. ELEC. 450V 100µF 0300256060
C6 Cap. Plastic 4700pF 0300269091
C7 Cap. Plastic 50V 0.047µF 0300169339
C8 Cap. Elec. 25V 100µF 0301197560
C9 Cap. Elec. 25V 1000µF 0301196495
C10,11,33, Cap. Elec. 25V 10µF 0301192312
36,41
C12 Cap. Elec. 25V 1000µF 0301158264
C13,15,34, Cap. Ceramic 50V 0.1µF 0300311752
37,39,44,45
C14 Cap. Elec. 25V 100µF 0301192350
C16~31,38, Cap. Ceramic 50V 0.01µF 0300311738
40,42,46,49
C32,35,43, Cap. Ceramic 50V 1000pF 0300308509
50~53
C54 Cap. Ceramic 50V 0.01µF 0300727539
K1,3,4 Relay JQ1-12V 9701316014
SSR1 Relay G3M-202P-UTU 9701829019
T1 Switching Transformer 9702727017
ETS28AS118AH
X1 Ceramic Resonator EF0EC8384T4 9701261017
BZ1 Buzzer PKM13EPY-4000-TF01 9701298013
CR1 Network RPEL-121204 9701125012
CN4 Plug, PCB B2P3-VH-B-Y 0500011827
CN5 Plug, PCB 5430C063 0500957026
CN6 Plug, PCB B2P3-VH-B-E 0500011759
CN7 Plug, PCB B2B-XAKK-1-A 0501045227
CN8 Plug, PCB B2B-XASK-1-A 0501045012
CN9 Plug, PCB B2P-SHF-1AA 0500006069
CN10 Plug, PCB B5B-XASK-1-A 0501045043
CN11 Plug, PCB B5B-XARK-1-A 0501045517
CN12 Plug, PCB B3B-XASK-1-A 0501045029
CN13 Plug, PCB B8B-XASK-1-A 0501045074
CN14 Plug, PCB B4B-XH-AM 0500005314
CN15 Plug, PCB B3B-XARK-1-A 0501045319
Part No. Part No.
CONTROLLER PCB ASSEMBLY (Ref. No. 236)
Ref. No. Ref. No.Description Description
Ord.
Q’ty
Ord.
Q’ty
D201 Diode SLR-325VC RED 0000813259
D202 Diode SLR-325MC GRN 0000813242
D203, 204 Diode SLR-325DC ORG 0000813235
C201 Cap. Ceramic 0.1µF 0300988251
C202 Cap. Elec. 25V 10µF 0300004258
R201~204 Res. Carbon 1/4W 330Ω±5% 0201038659
PHA201 Remote Control Amplifier 0101525129
SBX1810-22
SW201 Switch, EVQ-PAG-04K 9700450016
CN201 Wire w/Connector JC25/XMR 9701875016
Lamp Holder 94N40 9358548004
JM201 Wire 0.6dia. L=10mm 9700025016
Part No. Part No.
INDICATOR PCB ASSEMBLY (Ref. No. 385)
Ref. No. Ref. No.Description Description
Ord.
Q’ty
Ord.
Q’ty
C101, 102 Cap. Plastic 0.22µF 0300304099
C105, 106 Cap. Plastic 0.022µF 0301052098
SA101 Arrester DSA-362MA-05 0600168032
VA101, 102 Varistor TNR12G471K 0000038010
TM101, 102 Plug Contact 86028 0500536016
LF101 EMI Filter ELF17N015A 0400197119
F101 Fuse BET 3.15A-250V 0600222512
FH1, 2 Fuse Holder PFC5000-0502 0500158072
E101 Wire w/Terminal L=120mm GRN 9702066062
W101 Wire w/Terminal L=80mm BLK 9702066017
W102 Wire w/Terminal L=100mm WHT 9702066024
W103, 104 Wire #18 2p 9702067014
Part No. Part No.
FILTER PCB ASSEMBLY (Ref. No. 875)
To Next Page
