Fujitsu ABY54UBAG User Manual

INDOOR UNIT
H x W x D
240 x 1,660 x 700 mm
OUTDOOR UNIT
1,290 x 900 x 330 mm
DIMENSIONS
INDOOR UNIT
Gross / Net
H x W x D
Gross / Net
62 kg / 49 kg
OUTDOOR UNIT
121 kg / 114 kg 125 kg / 118 kg
WEIGHT
SPECIFICATIONS
TYPE COOLING COOL & HEAT
INDOOR UNIT ABY54FBAG ABY54UBAG
OUTDOOR UNIT AOY54FMAYT AOY54UMAYT
COOLING CAPACITY
14.5 kW
14.5 kW
HEATING CAPACITY
-------
16.5 kW
POWER SOURCE 400 V
FREQUENCY 3ø 50Hz
RUNNING CURRENT
Cooling
9.5 A
Heating
-------
9.5 A
INPUT WATTS
Cooling
5.16 kW
Heating
-------
5.30 kW
E.E.R.
Cooling
2.81 kW/kW
9.5 A
5.16 kW
2.81 kW/kW
Heating
------- 3.11 kW/kW
MOISTURE REMOVAL 6.0 L/hr
AIR CIRCULATION 2,200 m3/hr
FAN MOTOR
TYPE
Hermetic type, 2 poles, 3 phase,
Induced by condenser, Scroll
DISCRIMINATION BN65YEAMT
POWER SOURCE 400 V
Discrimination MFA-45DZM
High speed
1,250 r.p.m.
INDOOR UNIT
Med speed
1,150 r.p.m.
Low speed
1,000 r.p.m.
OUTDOOR UNIT
Discrimination MFB-30PTT x 2
High speed 780 r.p.m.
ELECTRICAL DATA
COMPRESSOR
REFRIGERANT AMOUNT (R410A)
3,300 g
3,500 g
20 m
Pipe length
30 m
3,700 g 3,900 g
40 m
4,100 g 4,300 g
50 m
4,500 g 4,700 g
ADDITIONAL CHARGE
FULL CHARGE
40 g/m
2005.10.31 1
