Fujitsu ACUH09LUAS1 User Manual

1. Specifications
1-1. Indoor unit
Type
Cassette
Inverter heat pump
Model name ACUH09LUAS1 ACUH12LUAS1 ACUH18LUAS1
Power supply 208/230 V ~ 60 Hz
Available voltage range 187—253 V
Capacity
Cooling Cooling
Rated
k→ 2.64 3.52 5.02
Btu/h 9,000 12,000 17,100
Min.—Max.
k→ 0.90—3.20 0.90—4.00 0.90—5.90
Btu/h 3,100—11,000 3,100—13,600 3,100—20,100
Heating
47 °FDB
(Outdoor temp.)
Rated
k→ 3.52 4.69 6.33
Btu/h 12,000 16,000 21,600
Min.—Max.
k→ 0.90—4.70 0.90—5.70 0.90—7.00
Btu/h 3,100—16,000 3,100—19,400 3,100—23,900
17 °FDB
(Outdoor temp.)
Rated
k→ 2.17 3.08 4.22
Btu/h 7,400 10,500 14,400
Max.
k→ 3.08 4.98 5.75
Btu/h 10,500 17,000 19,600
Input power
Cooling Cooling
Rated
k→
0.66 0.94 1.37
Max. 1.05 2.06 2.35
Heating
47 °FDB
(Outdoor temp.)
Rated 0.93 1.44 1.81
Max. 1.72 1.79 2.57
17 °FDB
(Outdoor temp.)
Rated 0.78 1.07 1.49
Max. 1.42 2.01 2.56
Current
Cooling
Rated A
3.3 4.2 6.1
Heating 4.6 6.4 8.1
EER Cooling
k→/k→ 4.00 3.74 3.66
Btu/h→ 13.6 12.8 12.5
COP Heating
k→/k→ 3.78 3.25 3.50
Btu/h→ 12.9 11.1 11.9
SEER Cooling Btu/h→ 22.5 22.1 20.8
HSPF Heating Btu/h→ 12.5 12.2 11.6
Power factor
Cooling
%
87.0 97.3 97.6
Heating 86.0 97.8 97.2
Moisture removal pints/h (L/h) 1.3 (0.6) 2.5 (1.2) 4.6 (2.2)
Maximum operating current *
1
Cooling
A
6.8 9.8 11.8
Heating 9.3 11.3 14.8
Fan
Airflow rate
Cooling
HIGH
CFM (m
3
/h)
318 (540) 359 (610) 435 (740)
MED 288 (490) 312 (530) 341 (580)
LO→ 259 (440) 276 (470) 288(490)
QUIET 230 (390) 241 (410)
Heating
HIGH 318 (540) 359 (610) 435 (740)
MED 288 (490) 312 (530) 341 (580)
LO→ 259 (440) 276 (470) 288 (490)
QUIET 230 (390) 241 (410)
Type × Q'ty Turbo × 1
Motor output → 54
Sound pressure level *
2
Cooling
HIGH
dB (A)
33 37 42
MED 32 33 36
LO→ 29 31 32
QUIET 28
Heating
HIGH 34 37 44
MED 32 33 40
LO→ 29 31 36
QUIET 27 28 30
Heat exchanger type
Dimensions (H × → × D) in (mm)
Main 1: 8-4/16 × 51-9/16 × 1/2
(210 × 1,310 × 13.3)
Main 2: 8-4/16 × 49-3/16 × 1/2
(210 × 1,250 × 13.3)
Fin pitch FPI
Main 1: 1.2
Main 2: 1.2
Rows × Stages
Main 1: 1 × 10
Main 2: 1 × 10
Pipe type Copper tube
Fin type Aluminum
Dimensions
(H × → × D)
Net
in (mm)
9-5/8 × 22-7/16 × 22-7/16 (245 × 570 × 570)
Gross 10-7/16 × 28-3/4 × 24-5/8 (265 × 730 × 625)
→eight
Net
lb (kg)
33 (15)
Gross 40 (18) 42 (19)
Connection pipe
Size
Liquid
in (mm)
Ø1/4 (Ø6.35)
Gas Ø3/8 (Ø9.52) Ø1/2 (Ø12.70)
Method Flare
Operation range
Cooling
°F (°C) 64 to 90 (18 to 32)
%RH 80 or less
Heating °F (°C) 60 to 86 (16 to 30)
Drain hose
Material HARD PVC
Size in (mm)
Ø3/4 (Ø20.7) [I.D.]
Ø1-1/16 (Ø26.6) [O.D.]
Cassette grille
(Grid type: Option)
Model name UTG-CCGFGA
Material PS
Color
→hite
Approximate color of Munsell 9PB 9.1/0.2
Dimensions
(H × → × D)
Net
in (mm)
1-15/16 × 24-7/16 × 24-7/16 (49 × 620 × 620)
Gross 4-3/4 × 30-1/8 × 29-3/4 (120 × 765 × 755)
→eight
Net
lb (kg)
5.1 (2.3)
Gross 10 (4.5)
1-1. Indoor unit - (01-1) - 1. Specifications
