Fujitsu ACUH12LUAS1 User Manual

¢ Indoor unit: 14,000 Btu
COOLING
Pipe length
m 5 7.5 10 15 20 25
m ft 16 25 33 49 66 82
Height difference H (m)
Indoor unit is higher than
outdoor unit *1
15 49 — — — 0.955 0.937 0.922
10 33 — — 0.974 0.962 0.945 0.930
7.5 25 — 0.988 0.978 0.966 0.948 0.934
5 16 0.997 0.992 0.982 0.970 0.952 0.937
0 0 1.005 1.000 0.990 0.978 0.960 0.945
Indoor unit is lower than
outdoor unit *2
-5 -16 1.005 1.000 0.990 0.978 0.960 0.945
-7.5 -25 — 1.000 0.990 0.978 0.960 0.945
-10 -33 — — 0.990 0.978 0.960 0.945
-15 -49 — — — 0.978 0.960 0.945
HEATING
Pipe length
m 5 7.5 10 15 20 25
m ft 16 25 33 49 66 82
Height difference H (m)
Indoor unit is higher than
outdoor unit *1
15 49 — — — 0.972 0.945 0.919
10 33 — — 0.992 0.972 0.945 0.919
7.5 25 — 1.000 0.992 0.972 0.945 0.919
5 16 1.000 1.000 0.992 0.972 0.945 0.919
0 0 1.000 1.000 0.992 0.972 0.945 0.919
Indoor unit is lower than
outdoor unit *2
-5 -16 0.995 0.995 0.987 0.967 0.940 0.914
-7.5 -25 — 0.993 0.985 0.965 0.938 0.912
-10 -33 — — 0.982 0.962 0.935 0.910
-15 -49 — — — 0.957 0.930 0.905
¢ Indoor unit: 18,000 Btu
COOLING
Pipe length
m 5 7.5 10 15 20 25
m ft 16 25 33 49 66 82
Height difference H (m)
Indoor unit is higher than
outdoor unit *1
15 49 — — — 0.968 0.961 0.954
10 33 — — 0.982 0.976 0.969 0.962
7.5 25 — 0.988 0.986 0.980 0.973 0.966
5 16 0.994 0.992 0.990 0.984 0.977 0.970
0 0 1.002 1.000 0.998 0.992 0.985 0.978
Indoor unit is lower than
outdoor unit *2
-5 -16 1.002 1.000 0.998 0.992 0.985 0.978
-7.5 -25 — 1.000 0.998 0.992 0.985 0.978
-10 -33 — — 0.998 0.992 0.985 0.978
-15 -49 — — — 0.992 0.985 0.978
HEATING
Pipe length
m 5 7.5 10 15 20 25
m ft 16 25 33 49 66 82
Height difference H (m)
Indoor unit is higher than
outdoor unit *1
15 49 — — — 0.967 0.943 0.917
10 33 — — 0.990 0.967 0.943 0.917
7.5 25 — 1.000 0.990 0.967 0.943 0.917
5 16 1.010 1.000 0.990 0.967 0.943 0.917
0 0 1.010 1.000 0.990 0.967 0.943 0.917
Indoor unit is lower than
outdoor unit *2
-5 -16 1.005 0.995 0.985 0.962 0.938 0.912
-7.5 -25 — 0.993 0.983 0.960 0.936 0.910
-10 -33 — — 0.980 0.958 0.933 0.908
-15 -49 — — — 0.953 0.929 0.903
- 296 -
7-1. Model: AOU45RLXFZ 7. Capacity compensation rate for pipe length and height difference
OUTDOOR UNIT AOU45RLXFZ OUTDOOR UNIT AOU45RLXFZ
