Item no. Part no. Part name Service part
1 9377760043 Flap total assy ♦
2 9377759047 Flap assy B ♦
3 9375727048 Flap assy A ♦
4 9375746018 Motor holder assy B ♦
5 9900139087 Step motor (with Red connector) ♦
6 9375530013 Panel cover ♦
7 9711310002 Indicator PCB ♦
8 9383100024 Display panel assy ♦
9 9375549015 Connector cover ♦
10 9382862008 Intake grille assy ♦
11 9375546014 Hook bracket ♦
12 9375532031 Grille hook ♦
13 9382863005 Intake grille ♦
14 9375533014 Long-life filter ♦
15 9382821012 Decoration panel ♦
16 9375745011 Motor holder assy A ♦
17 9900139070 Step motor (with →hite connector) ♦
— 9711276001 →ire with connector ♦
2-1. Model: UTG-CCGFGA - (02-3) - 2. Cassette grille (optional part) parts list
