Fujitsu ACUH18LUAS1 Service Manual

Item no. Part no. Part name Service part
1 9900826000 Thermistor (Room) ♦
2 9900349028 Thermistor (Pipe) ♦
3 9900896027 Terminal 5P ♦
4
9711870032 Main PCB (09 model) ♦
9711870049 Main PCB (12 model) ♦
9711870056 Main PCB (18 model) ♦
5 9710019005 Communication PCB ♦
6 0600063023 Holder ♦
7 9900568009 Terminal 3P ♦
8 9350720002 Conduit plate ♦
9 9710661020 Power supply PCB ♦
10 9379665032 Drain hose ♦
11 9379757010 Hose band ♦
12 9375516017 →ire cover ♦
13 9375515027 Pipe cover ♦
14 9375718015 Drain port sub assy ♦
15 9375717025 Drain pump sub assy ♦
16 9375721046 Float switch sub assy ♦
17 9375477011 Thermistor holder ♦
18 9375503017 Bell-mouth hood ♦
19 9377765024 Drain pan sub assy ♦
— 9707449013
→ire with connector
(CN11 on Main PCB—Step motor)
♦
— 9711277008
→ire with connector
(CN12 on Main PCB—Step motor)
♦
— 9710177088
→ire with connector
(CN46 on Main PCB—Terminal [Ex. in])
♦
— 9711275004
→ire with connector
(CN48 on Main PCB—CN1 on Indicator PCB of optional
Cassette grille)
♦
— 9710171000
→ire with connector
(CN54 on Main PCB—CN262 on Power supply PCB)
♦
— 9710172007
→ire with connector
(CN55 on Main PCB—CN263 on Power supply PCB)
♦
— 9710343100
→ire with connector
(CN300 on Main PCB—Terminal [RC])
♦
— 9710703027
→ire with connector
(CN205 on Power supply PCB—Terminal 3P)
♦
— 9711278012
→ire with connector
(CN520 on Power supply PCB—DC fan motor)
♦
a — →ire holder —
3-1. Models: ACUH09LUAS1, ACUH12LUAS1, and ACUH18LUAS1 - (02-5) - 3. Indoor unit parts list
TECHNICAL DATA AND PARTS LIST TECHNICAL DATA AND PARTS LIST
