Item no. Part no. Part name Service part

50 9375719029 Fan motor sub assy ♦

51 9602870004 DC fan motor ♦

52 9375480011 2-stage turbo fan assy ♦

53 9377811011 →asher cover ♦

9375720384 Evaporator sub assy (09 and 12 models) ♦

9375720339 Evaporator sub assy (18 model) ♦

55 9377764065 Insulation box sub assy ♦

56 9377807014 Shaft cap ♦

a — Top plate assy —

b — Motor wire holder —

c — Cabinet A sub assy —

d — Separate wall —

e — Evaporator holder —

f — Cabinet B sub assy —

3-1. Models: ACUH09LUAS1, ACUH12LUAS1, and ACUH18LUAS1 - (02-7) - 3. Indoor unit parts list
