2-1-2. V-II (230V) series
SETTINGS LIST
LED105
CODE
No.
Setting Mode
LED104
CODE No.
Setting Function
Factory
setting
Outdoor unit
Remarks
Master Slave
0 0
Pipe length
setting
0 0
Standard (131 to 213ft.)
(40 to 65m)
l
¡
-
*1
Pipe length means the length
between master outdoor unit
and the nearest indoor unit.
0 1
Short (less than 131ft.)
(less than 40m)
0 2
Medium (213 to 295ft.)
(65 to 90m)
0 3
Long 1 (295 to 394ft.)
(90 to 120m)
0 4
Long 2 (394 to 492ft.)
(120 to 150m)
1 0
Sequential start
shift
0 0 Normal
l
¡
-
*1
The start-up timing of outdoor
unit (compressor) can be set
up so that it can delay several
seconds.
This feature is useful when
multiple number of outdoor units
are installed and turned on at
the same time
to limit the starting current.
0 1 21sec. Delay
0 2 42sec. Delay
0 3 63sec. Delay
1 1
Cooling
capacity shift
0 0 Normal mode
l
¡
-
*1
0 1 Save energy mode
0 2 High power mode 1
0 3 High power mode 2
0 4 Prohibited
1 2
Heating
capacity shift
0 0 Normal mode
l
¡
-
*1
0 1 Save energy mode
0 2 High power mode 1
0 3 High power mode 2
1 3 Prohibited
0 0 Prohibited
l
Setting prohibited
0 1 Prohibited
2 0
Switching
between
batch stop or
emergency stop
0 0 Batch stop
l
¡
-
*1
This mode selects the pattern of
the stop function to be operated
by the external input terminal
(CN134).
•Batch stop: The stop of all
indoor units connected to same
refrigerant system due to input
signal coming from CN134.
•Emergency stop: When
emergency stop is actuated, the
indoor unit does not accept the
operation command from the
remote controller. On the other
hand, when the emergency
stop is released (no input from
CN134), the air conditioner
does not return to the original
operation until the indoor unit
is turned on by the remote
controller.
0 1 Emergency stop
*1: Do not set this for outdoor units with Slave setting.
