Fujitsu AO G12KATA Series Design & Technical Manual

¢
Model: ARXG14KSLAP
80
70
60
50
40
30
20
10
0
External static pressure (Pa)
300
400 500 600 700
Airflow (m
3
/h)
800 900
Hi (SP mode 05)
Hi (Normal SP)
SP mode 05
upper limit
SP mode 05
lower limit
Quiet
(SP mode 05)
Nomal SP
upper limit
SP mode 00
upper limit
Quiet
(Nomal SP)
Hi
(SP mode 00)
Quiet
(SP mode 00)
80
70
60
50
40
30
20
10
0
External static pressure (Pa)
300 400 500 600 700
Airflow (m
3
/h)
800 900
*1: Available airflow rate range when Auto louver grille (option) is installed.
Fan speed: HIGH
Vertical airflow direction louver: Up
Hi (SP mode 01)
Hi (SP mode 05)
Hi (SP mode 04)
Hi (SP mode 03)
Hi (Normal SP)
Hi (SP mode 02)
Hi (SP mode 00)
Available airflow rate range (High level)
*1
- 124 -
7-1. Mini duct type
7. Fan performance
