Fujitsu AO G12KATA Series Design & Technical Manual

6. Capacity table
6-1. Combinations
¢
Model: AOYG36KBTA5

Cooling
Combination of indoor unit Rated capacity for each indoor unit (kW)
Total capacity
(kW)
Input power (kW)
EER
(W/W)
Seasonal data
Room
Total
Room
Min. Rated Max. Min. Rated Max.
Pdesign
(kW)
SEER
(kWh/kWh)
Energy effi-
ciency class
1 2 3 4 5 1 2 3 4 5
7 24 — — — 31 2.00 7.00 — — — 3.0 9.00 11.0 0.30 2.91 3.45 3.09 9.0 7.9 A++
9 22 — — — 31 2.50 6.00 — — — 3.0 8.50 11.0 0.30 2.67 3.45 3.18 8.5 7.9 A++
9 24 — — — 33 2.50 7.00 — — — 3.0 9.50 11.0 0.30 3.17 3.45 3.00 9.5 7.8 A++
12 22 — — — 34 3.50 6.00 — — — 3.0 9.50 11.0 0.30 3.17 3.45 3.00 9.5 7.8 A++
12 24 — — — 36 3.17 6.33 — — — 3.0 9.50 11.0 0.30 3.17 3.45 3.00 9.5 7.8 A++
14 22 — — — 36 3.69 5.81 — — — 3.0 9.50 11.0 0.30 3.17 3.45 3.00 9.5 7.8 A++
14 24 — — — 38 3.50 6.00 — — — 3.0 9.50 11.0 0.30 3.17 3.45 3.00 9.5 7.8 A++
18 18 — — — 36 4.75 4.75 — — — 3.0 9.50 11.0 0.30 3.17 3.45 3.00 9.5 7.8 A++
18 22 — — — 40 4.27 5.23 — — — 3.0 9.50 11.0 0.30 3.17 3.45 3.00 9.5 7.8 A++
18 24 — — — 42 4.07 5.43 — — — 3.0 9.50 11.0 0.30 3.17 3.45 3.00 9.5 7.8 A++
22 22 — — — 44 4.75 4.75 — — — 3.0 9.50 11.0 0.30 3.17 3.45 3.00 9.5 7.8 A++
22 24 — — — 46 4.54 4.96 — — — 3.0 9.50 11.0 0.30 3.17 3.45 3.00 9.5 7.8 A++
24 24 — — — 48 4.75 4.75 — — — 3.0 9.50 11.0 0.30 3.17 3.45 3.00 9.5 7.8 A++
7 7 14 — — 28 2.00 2.00 4.00 — — 3.0 8.00 10.0 0.30 2.26 2.88 3.54 8.0 8.2 A++
7 7 18 — — 32 2.00 2.00 5.00 — — 3.0 9.00 11.0 0.30 2.68 3.45 3.36 9.0 8.1 A++
7 7 22 — — 36 1.85 1.85 5.80 — — 3.0 9.50 11.0 0.30 2.91 3.45 3.27 9.5 8.0 A++
7 7 24 — — 38 1.75 1.75 6.00 — — 3.0 9.50 11.0 0.30 2.91 3.45 3.27 9.5 8.0 A++
7 9 12 — — 28 2.00 2.50 3.50 — — 3.0 8.00 10.0 0.30 2.26 2.88 3.54 8.0 8.2 A++
7 9 14 — — 30 2.00 2.50 4.00 — — 3.0 8.50 10.7 0.30 2.46 3.27 3.45 8.5 8.1 A++
7 9 18 — — 34 2.00 2.50 5.00 — — 3.0 9.50 11.0 0.30 2.91 3.45 3.27 9.5 8.0 A++
7 9 22 — — 38 1.75 2.25 5.50 — — 3.0 9.50 11.0 0.30 2.91 3.45 3.27 9.5 8.0 A++
7 9 24 — — 40 1.66 2.14 5.70 — — 3.0 9.50 11.0 0.30 2.91 3.45 3.27 9.5 8.0 A++
7 12 12 — — 31 2.00 3.50 3.50 — — 3.0 9.00 11.0 0.30 2.68 3.45 3.36 9.0 8.1 A++
7 12 14 — — 33 2.00 3.50 4.00 — — 3.0 9.50 11.0 0.30 2.91 3.45 3.27 9.5 8.0 A++
7 12 18 — — 37 1.80 3.08 4.62 — — 3.0 9.50 11.0 0.30 2.91 3.45 3.27 9.5 8.0 A++
7 12 22 — — 41 1.62 2.78 5.10 — — 3.0 9.50 11.0 0.30 2.91 3.45 3.27 9.5 8.0 A++
7 12 24 — — 43 1.55 2.65 5.30 — — 3.0 9.50 11.0 0.30 2.91 3.45 3.27 9.5 8.0 A++
7 14 14 — — 35 1.90 3.80 3.80 — — 3.0 9.50 11.0 0.30 2.91 3.45 3.27 9.5 8.0 A++
7 14 18 — — 39 1.71 3.41 4.38 — — 3.0 9.50 11.0 0.30 2.91 3.45 3.27 9.5 8.0 A++
7 14 22 — — 43 1.55 3.09 4.86 — — 3.0 9.50 11.0 0.30 2.91 3.45 3.27 9.5 8.0 A++
7 14 24 — — 45 1.47 2.96 5.07 — — 3.0 9.50 11.0 0.30 2.91 3.45 3.27 9.5 8.0 A++
7 18 18 — — 43 1.54 3.98 3.98 — — 3.0 9.50 11.0 0.30 2.91 3.45 3.27 9.5 8.0 A++
7 18 22 — — 47 1.41 3.64 4.45 — — 3.0 9.50 11.0 0.30 2.91 3.45 3.27 9.5 8.0 A++
7 18 24 — — 49 1.36 3.49 4.65 — — 3.0 9.50 11.0 0.30 2.91 3.45 3.27 9.5 8.0 A++
9 9 9 — — 27 2.50 2.50 2.50 — — 3.0 7.50 9.6 0.30 2.07 2.70 3.63 7.5 8.2 A++
9 9 12 — — 30 2.50 2.50 3.50 — — 3.0 8.50 10.7 0.30 2.46 3.27 3.45 8.5 8.1 A++
9 9 14 — — 32 2.50 2.50 4.00 — — 3.0 9.00 11.0 0.30 2.68 3.45 3.36 9.0 8.1 A++
9 9 18 — — 36 2.38 2.38 4.74 — — 3.0 9.50 11.0 0.30 2.91 3.45 3.27 9.5 8.0 A++
9 9 22 — — 40 2.14 2.14 5.22 — — 3.0 9.50 11.0 0.30 2.91 3.45 3.27 9.5 8.0 A++
9 9 24 — — 42 2.04 2.04 5.42 — — 3.0 9.50 11.0 0.30 2.91 3.45 3.27 9.5 8.0 A++
9 12 12 — — 33 2.50 3.50 3.50 — — 3.0 9.50 11.0 0.30 2.91 3.45 3.27 9.5 8.0 A++
9 12 14 — — 35 2.44 3.26 3.80 — — 3.0 9.50 11.0 0.30 2.91 3.45 3.27 9.5 8.0 A++
9 12 18 — — 39 2.19 2.92 4.39 — — 3.0 9.50 11.0 0.30 2.91 3.45 3.27 9.5 8.0 A++
9 12 22 — — 43 1.99 2.65 4.86 — — 3.0 9.50 11.0 0.30 2.91 3.45 3.27 9.5 8.0 A++
9 12 24 — — 45 1.90 2.53 5.07 — — 3.0 9.50 11.0 0.30 2.91 3.45 3.27 9.5 8.0 A++
9 14 14 — — 37 2.32 3.59 3.59 — — 3.0 9.50 11.0 0.30 2.91 3.45 3.27 9.5 8.0 A++
9 14 18 — — 41 2.09 3.24 4.17 — — 3.0 9.50 11.0 0.30 2.91 3.45 3.27 9.5 8.0 A++
9 14 22 — — 45 1.90 2.96 4.64 — — 3.0 9.50 11.0 0.30 2.91 3.45 3.27 9.5 8.0 A++
9 14 24 — — 47 1.82 2.83 4.85 — — 3.0 9.50 11.0 0.30 2.91 3.45 3.27 9.5 8.0 A++
9 18 18 — — 45 1.90 3.80 3.80 — — 3.0 9.50 11.0 0.30 2.91 3.45 3.27 9.5 8.0 A++
9 18 22 — — 49 1.74 3.49 4.27 — — 3.0 9.50 11.0 0.30 2.91 3.45 3.27 9.5 8.0 A++
9 18 24 — — 51 1.68 3.35 4.47 — — 3.0 9.50 11.0 0.30 2.91 3.45 3.27 9.5 8.0 A++
12 12 12 — — 36 3.17 3.17 3.17 — — 3.0 9.50 11.0 0.30 2.91 3.45 3.27 9.5 8.0 A++
12 12 14 — — 38 3.00 3.00 3.50 — — 3.0 9.50 11.0 0.30 2.91 3.45 3.27 9.5 8.0 A++
12 12 18 — — 42 2.71 2.71 4.08 — — 3.0 9.50 11.0 0.30 2.91 3.45 3.27 9.5 8.0 A++
12 12 22 — — 46 2.48 2.48 4.54 — — 3.0 9.50 11.0 0.30 2.91 3.45 3.27 9.5 8.0 A++
12 12 24 — — 48 2.38 2.38 4.74 — — 3.0 9.50 11.0 0.30 2.91 3.45 3.27 9.5 8.0 A++
12 14 14 — — 40 2.84 3.33 3.33 — — 3.0 9.50 11.0 0.30 2.91 3.45 3.27 9.5 8.0 A++
12 14 18 — — 44 2.59 3.02 3.89 — — 3.0 9.50 11.0 0.30 2.91 3.45 3.27 9.5 8.0 A++
12 14 22 — — 48 2.38 2.77 4.35 — — 3.0 9.50 11.0 0.30 2.91 3.45 3.27 9.5 8.0 A++
12 14 24 — — 50 2.28 2.66 4.56 — — 3.0 9.50 11.0 0.30 2.91 3.45 3.27 9.5 8.0 A++
12 18 18 — — 48 2.38 3.56 3.56 — — 3.0 9.50 11.0 0.30 2.91 3.45 3.27 9.5 8.0 A++
12 18 22 — — 52 2.19 3.29 4.02 — — 3.0 9.50 11.0 0.30 2.91 3.45 3.27 9.5 8.0 A++
12 18 24 — — 54 2.11 3.17 4.22 — — 3.0 9.50 11.0 0.30 2.91 3.45 3.27 9.5 8.0 A++
14 14 14 — — 42 3.17 3.17 3.17 — — 3.0 9.50 11.0 0.30 2.91 3.45 3.27 9.5 8.0 A++
14 14 18 — — 46 2.89 2.89 3.72 — — 3.0 9.50 11.0 0.30 2.91 3.45 3.27 9.5 8.0 A++
14 14 22 — — 50 2.66 2.66 4.18 — — 3.0 9.50 11.0 0.30 2.91 3.45 3.27 9.5 8.0 A++
14 14 24 — — 52 2.56 2.56 4.38 — — 3.0 9.50 11.0 0.30 2.91 3.45 3.27 9.5 8.0 A++
14 18 18 — — 50 2.66 3.42 3.42 — — 3.0 9.50 11.0 0.30 2.91 3.45 3.27 9.5 8.0 A++
18 18 18 — — 54 3.17 3.17 3.17 — — 3.0 9.50 11.0 0.30 2.91 3.45 3.27 9.5 8.0 A++
7 7 7 7 — 28 2.00 2.00 2.00 2.00 — 3.0 8.00 10.0 0.30 2.11 2.88 3.80 8.0 8.5 A+++
7 7 7 9 — 30 2.00 2.00 2.00 2.50 — 3.0 8.50 10.7 0.30 2.29 3.27 3.71 8.5 8.4 A++
7 7 7 12 — 33 2.00 2.00 2.00 3.50 — 3.0 9.50 11.0 0.30 2.69 3.45 3.53 9.5 8.3 A++
