Fujitsu AO G12KATA Series Design & Technical Manual

Indoor unit connect-
ing capacity
Outdoor temperature
Indoor temperature
18.0 °CDB 21.0 °CDB 23.0 °CDB 27.0 °CDB 29.0 °CDB 32.0 °CDB
12.0 °CWB 15.0 °CWB 16.0 °CWB 19.0 °CWB 21.0 °CWB 23.0 °CWB
kBtu/h °CDB TC IP TC IP TC IP TC IP TC IP TC IP
34
-10.0 7.9 1.94 8.9 1.97 9.4 1.99 10.1 2.01 10.8 2.03 11.1 2.05
0.0 7.9 2.02 8.9 2.05 9.4 2.07 10.1 2.09 10.8 2.11 11.1 2.13
5.0 7.9 1.98 8.9 2.02 9.4 2.03 10.1 2.05 10.8 2.08 11.1 2.09
10.0 7.9 2.11 8.9 2.14 9.4 2.16 10.1 2.19 10.8 2.21 11.1 2.22
15.0 7.9 2.00 8.9 2.04 9.4 2.05 10.1 2.08 10.8 2.10 11.1 2.11
20.0 7.9 1.89 8.9 1.93 9.4 1.94 10.1 1.97 10.8 1.99 11.1 2.00
25.0 7.9 2.29 8.9 2.33 9.4 2.35 10.1 2.38 10.8 2.40 11.1 2.42
30.0 7.9 2.74 8.9 2.79 9.4 2.82 10.1 2.85 10.8 2.88 11.1 2.90
35.0 7.9 3.18 8.9 3.24 9.4 3.26 10.1 3.30 10.8 3.34 11.1 3.35
40.0 6.6 2.69 7.4 2.74 7.8 2.76 8.4 2.79 8.9 2.82 9.2 2.84
46.0 5.2 2.20 5.9 2.24 6.2 2.25 6.6 2.28 7.1 2.31 7.3 2.32
33
-10.0 7.9 1.94 8.9 1.97 9.4 1.99 10.1 2.01 10.8 2.03 11.1 2.05
0.0 7.9 2.02 8.9 2.05 9.4 2.07 10.1 2.09 10.8 2.11 11.1 2.13
5.0 7.9 1.98 8.9 2.02 9.4 2.03 10.1 2.05 10.8 2.08 11.1 2.09
10.0 7.9 2.11 8.9 2.14 9.4 2.16 10.1 2.19 10.8 2.21 11.1 2.22
15.0 7.9 2.00 8.9 2.04 9.4 2.05 10.1 2.08 10.8 2.10 11.1 2.11
20.0 7.9 1.89 8.9 1.93 9.4 1.94 10.1 1.97 10.8 1.99 11.1 2.00
25.0 7.9 2.29 8.9 2.33 9.4 2.35 10.1 2.38 10.8 2.40 11.1 2.42
30.0 7.9 2.74 8.9 2.79 9.4 2.82 10.1 2.85 10.8 2.88 11.1 2.90
35.0 7.9 3.18 8.9 3.24 9.4 3.26 10.1 3.30 10.8 3.34 11.1 3.35
40.0 6.6 2.69 7.4 2.74 7.8 2.76 8.4 2.79 8.9 2.82 9.2 2.84
46.0 5.2 2.20 5.9 2.24 6.2 2.25 6.6 2.28 7.1 2.31 7.3 2.32
32
-10.0 7.9 1.94 8.9 1.97 9.4 1.99 10.1 2.01 10.8 2.03 11.1 2.05
0.0 7.9 2.02 8.9 2.05 9.4 2.07 10.1 2.09 10.8 2.11 11.1 2.13
5.0 7.9 1.98 8.9 2.02 9.4 2.03 10.1 2.05 10.8 2.08 11.1 2.09
10.0 7.9 2.11 8.9 2.14 9.4 2.16 10.1 2.19 10.8 2.21 11.1 2.22
15.0 7.9 2.00 8.9 2.04 9.4 2.05 10.1 2.08 10.8 2.10 11.1 2.11
20.0 7.9 1.89 8.9 1.93 9.4 1.94 10.1 1.97 10.8 1.99 11.1 2.00
25.0 7.9 2.29 8.9 2.33 9.4 2.35 10.1 2.38 10.8 2.40 11.1 2.42
30.0 7.9 2.74 8.9 2.79 9.4 2.82 10.1 2.85 10.8 2.88 11.1 2.90
35.0 7.9 3.18 8.9 3.24 9.4 3.26 10.1 3.30 10.8 3.34 11.1 3.35
40.0 6.6 2.69 7.4 2.74 7.8 2.76 8.4 2.79 8.9 2.82 9.2 2.84
46.0 5.2 2.20 5.9 2.24 6.2 2.25 6.6 2.28 7.1 2.31 7.3 2.32
31
-10.0 7.9 1.94 8.9 1.97 9.4 1.99 10.1 2.01 10.8 2.03 11.1 2.05
0.0 7.9 2.02 8.9 2.05 9.4 2.07 10.1 2.09 10.8 2.11 11.1 2.13
5.0 7.9 1.98 8.9 2.02 9.4 2.03 10.1 2.05 10.8 2.08 11.1 2.09
10.0 7.9 2.11 8.9 2.14 9.4 2.16 10.1 2.19 10.8 2.21 11.1 2.22
15.0 7.9 2.00 8.9 2.04 9.4 2.05 10.1 2.08 10.8 2.10 11.1 2.11
20.0 7.9 1.89 8.9 1.93 9.4 1.94 10.1 1.97 10.8 1.99 11.1 2.00
25.0 7.9 2.29 8.9 2.33 9.4 2.35 10.1 2.38 10.8 2.40 11.1 2.42
30.0 7.9 2.74 8.9 2.79 9.4 2.82 10.1 2.85 10.8 2.88 11.1 2.90
35.0 7.9 3.18 8.9 3.24 9.4 3.26 10.1 3.30 10.8 3.34 11.1 3.35
40.0 6.6 2.69 7.4 2.74 7.8 2.76 8.4 2.79 8.9 2.82 9.2 2.84
46.0 5.2 2.20 5.9 2.24 6.2 2.25 6.6 2.28 7.1 2.31 7.3 2.32
30
-10.0 7.9 1.94 8.9 1.97 9.4 1.99 10.1 2.01 10.8 2.03 11.1 2.05
0.0 7.9 2.02 8.9 2.05 9.4 2.07 10.1 2.09 10.8 2.11 11.1 2.13
5.0 7.9 1.98 8.9 2.02 9.4 2.03 10.1 2.05 10.8 2.08 11.1 2.09
10.0 7.9 2.11 8.9 2.14 9.4 2.16 10.1 2.19 10.8 2.21 11.1 2.22
15.0 7.9 2.00 8.9 2.04 9.4 2.05 10.1 2.08 10.8 2.10 11.1 2.11
20.0 7.9 1.89 8.9 1.93 9.4 1.94 10.1 1.97 10.8 1.99 11.1 2.00
25.0 7.9 2.29 8.9 2.33 9.4 2.35 10.1 2.38 10.8 2.40 11.1 2.42
30.0 7.9 2.74 8.9 2.79 9.4 2.82 10.1 2.85 10.8 2.88 11.1 2.90
35.0 7.9 3.18 8.9 3.24 9.4 3.26 10.1 3.30 10.8 3.34 11.1 3.35
40.0 6.6 2.69 7.4 2.74 7.8 2.76 8.4 2.79 8.9 2.82 9.2 2.84
46.0 5.2 2.20 5.9 2.24 6.2 2.25 6.6 2.28 7.1 2.31 7.3 2.32
29
-10.0 7.9 1.94 8.9 1.97 9.4 1.99 10.1 2.01 10.8 2.03 11.1 2.05
0.0 7.9 2.02 8.9 2.05 9.4 2.07 10.1 2.09 10.8 2.11 11.1 2.13
5.0 7.9 1.98 8.9 2.02 9.4 2.03 10.1 2.05 10.8 2.08 11.1 2.09
10.0 7.9 2.11 8.9 2.14 9.4 2.16 10.1 2.19 10.8 2.21 11.1 2.22
15.0 7.9 2.00 8.9 2.04 9.4 2.05 10.1 2.08 10.8 2.10 11.1 2.11
20.0 7.9 1.89 8.9 1.93 9.4 1.94 10.1 1.97 10.8 1.99 11.1 2.00
25.0 7.9 2.29 8.9 2.33 9.4 2.35 10.1 2.38 10.8 2.40 11.1 2.42
30.0 7.9 2.74 8.9 2.79 9.4 2.82 10.1 2.85 10.8 2.88 11.1 2.90
35.0 7.9 3.18 8.9 3.24 9.4 3.26 10.1 3.30 10.8 3.34 11.1 3.35
40.0 6.6 2.69 7.4 2.74 7.8 2.76 8.4 2.79 8.9 2.82 9.2 2.84
46.0 5.2 2.20 5.9 2.24 6.2 2.25 6.6 2.28 7.1 2.31 7.3 2.32
28
-10.0 7.9 1.94 8.9 1.97 9.4 1.99 10.1 2.01 10.8 2.03 11.1 2.05
0.0 7.9 2.02 8.9 2.05 9.4 2.07 10.1 2.09 10.8 2.11 11.1 2.13
5.0 7.9 1.98 8.9 2.02 9.4 2.03 10.1 2.05 10.8 2.08 11.1 2.09
10.0 7.9 2.11 8.9 2.14 9.4 2.16 10.1 2.19 10.8 2.21 11.1 2.22
15.0 7.9 2.00 8.9 2.04 9.4 2.05 10.1 2.08 10.8 2.10 11.1 2.11
20.0 7.9 1.89 8.9 1.93 9.4 1.94 10.1 1.97 10.8 1.99 11.1 2.00
25.0 7.9 2.29 8.9 2.33 9.4 2.35 10.1 2.38 10.8 2.40 11.1 2.42
30.0 7.9 2.74 8.9 2.79 9.4 2.82 10.1 2.85 10.8 2.88 11.1 2.90
35.0 7.9 3.18 8.9 3.24 9.4 3.26 10.1 3.30 10.8 3.34 11.1 3.35
40.0 6.6 2.69 7.4 2.74 7.8 2.76 8.4 2.79 8.9 2.82 9.2 2.84
46.0 5.2 2.20 5.9 2.24 6.2 2.25 6.6 2.28 7.1 2.31 7.3 2.32
27
-10.0 7.5 1.77 8.5 1.80 9.0 1.81 9.6 1.83 10.3 1.85 10.6 1.86
0.0 7.5 1.84 8.5 1.87 9.0 1.88 9.6 1.90 10.3 1.93 10.6 1.94
5.0 7.5 1.80 8.5 1.84 9.0 1.85 9.6 1.87 10.3 1.89 10.6 1.90
10.0 7.5 1.92 8.5 1.95 9.0 1.97 9.6 1.99 10.3 2.01 10.6 2.03
15.0 7.5 1.82 8.5 1.86 9.0 1.87 9.6 1.89 10.3 1.91 10.6 1.92
20.0 7.5 1.73 8.5 1.76 9.0 1.77 9.6 1.79 10.3 1.81 10.6 1.82
25.0 7.5 2.09 8.5 2.12 9.0 2.14 9.6 2.17 10.3 2.19 10.6 2.20
30.0 7.5 2.50 8.5 2.54 9.0 2.57 9.6 2.59 10.3 2.62 10.6 2.64
35.0 7.5 2.90 8.5 2.95 9.0 2.97 9.6 3.00 10.3 3.04 10.6 3.06
40.0 6.2 2.45 7.0 2.49 7.4 2.51 7.9 2.54 8.5 2.57 8.8 2.58
46.0 6.2 2.00 7.0 2.04 7.4 2.05 7.9 2.08 8.5 2.10 8.8 2.11
- 396 -
6-2. Cooling capacity
6. Capacity table
OUTDOOR UNIT AOYG30KBTA4
OUTDOOR UNIT
AOYG30KBTA4

Fujitsu AO G12KATA Series Specifications
