Fujitsu AO G12KATA Series Design & Technical Manual

Model: AUXG18KVLA
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 4.75 2.88 5.37 3.28 5.66 3.78 6.06 4.24 6.48 4.64 6.68 5.32
-5.0 4.75 2.88 5.37 3.28 5.66 3.78 6.06 4.24 6.48 4.64 6.68 5.32
0.0 4.75 2.88 5.37 3.28 5.66 3.78 6.06 4.24 6.48 4.64 6.68 5.32
5.0 4.75 2.88 5.37 3.28 5.66 3.78 6.06 4.24 6.48 4.64 6.68 5.32
10.0 4.75 2.88 5.37 3.28 5.66 3.78 6.06 4.24 6.48 4.64 6.68 5.32
15.0 4.75 2.88 5.37 3.28 5.66 3.78 6.06 4.24 6.48 4.64 6.68 5.32
20.0 4.75 2.88 5.37 3.28 5.66 3.78 6.06 4.24 6.48 4.64 6.68 5.32
25.0 4.75 2.88 5.37 3.28 5.66 3.78 6.06 4.24 6.48 4.64 6.68 5.32
30.0 4.75 2.88 5.37 3.28 5.66 3.78 6.06 4.24 6.48 4.64 6.68 5.32
35.0 4.75 2.88 5.37 3.28 5.66 3.78 6.06 4.24 6.48 4.64 6.68 5.32
40.0 3.93 1.97 4.44 2.25 4.68 2.59 5.02 2.91 5.36 3.18 5.53 3.64
46.0 3.11 1.24 3.52 1.41 3.71 1.62 3.97 1.82 4.25 1.99 4.38 2.28
Model: AUXG22KVLA
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 6.01 3.65 6.79 4.16 7.15 4.80 7.66 5.39 8.19 5.89 8.44 6.75
-5.0 6.01 3.65 6.79 4.16 7.15 4.80 7.66 5.39 8.19 5.89 8.44 6.75
0.0 6.01 3.65 6.79 4.16 7.15 4.80 7.66 5.39 8.19 5.89 8.44 6.75
5.0 6.01 3.65 6.79 4.16 7.15 4.80 7.66 5.39 8.19 5.89 8.44 6.75
10.0 6.01 3.65 6.79 4.16 7.15 4.80 7.66 5.39 8.19 5.89 8.44 6.75
15.0 6.01 3.65 6.79 4.16 7.15 4.80 7.66 5.39 8.19 5.89 8.44 6.75
20.0 6.01 3.65 6.79 4.16 7.15 4.80 7.66 5.39 8.19 5.89 8.44 6.75
25.0 6.01 3.65 6.79 4.16 7.15 4.80 7.66 5.39 8.19 5.89 8.44 6.75
30.0 6.01 3.65 6.79 4.16 7.15 4.80 7.66 5.39 8.19 5.89 8.44 6.75
35.0 6.01 3.65 6.79 4.16 7.15 4.80 7.66 5.39 8.19 5.89 8.44 6.75
40.0 4.97 2.50 5.62 2.85 5.92 3.28 6.34 3.69 6.78 4.04 6.99 4.62
46.0 3.94 1.57 4.45 1.79 4.69 2.06 5.02 2.31 5.37 2.53 5.53 2.90
NOTES:
• TC: Total Capacity (kW), SHC: Sensible Heat Capacity (kW)
• Values mentioned in the table are based on the following conditions:
– Pipe length: 5 m, Height difference: 0 m (Outdoor unit—Indoor unit)
- 399 -
6-2. Cooling capacity
6. Capacity table
OUTDOOR UNIT AOYG30KBTA4
OUTDOOR UNIT
AOYG30KBTA4

Fujitsu AO G12KATA Series Specifications

General

Brand	Fujitsu
Model	AO G12KATA Series
Category	Air Conditioner
Language	English
