Fujitsu AO G12KATA Series Design & Technical Manual

Model: ARXG18KLLAP
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 4.75 2.96 5.37 3.37 5.66 3.88 6.06 4.36 6.48 4.77 6.68 5.47
-5.0 4.75 2.96 5.37 3.37 5.66 3.88 6.06 4.36 6.48 4.77 6.68 5.47
0.0 4.75 2.96 5.37 3.37 5.66 3.88 6.06 4.36 6.48 4.77 6.68 5.47
5.0 4.75 2.96 5.37 3.37 5.66 3.88 6.06 4.36 6.48 4.77 6.68 5.47
10.0 4.75 2.96 5.37 3.37 5.66 3.88 6.06 4.36 6.48 4.77 6.68 5.47
15.0 4.75 2.96 5.37 3.37 5.66 3.88 6.06 4.36 6.48 4.77 6.68 5.47
20.0 4.75 2.96 5.37 3.37 5.66 3.88 6.06 4.36 6.48 4.77 6.68 5.47
25.0 4.75 2.96 5.37 3.37 5.66 3.88 6.06 4.36 6.48 4.77 6.68 5.47
30.0 4.75 2.96 5.37 3.37 5.66 3.88 6.06 4.36 6.48 4.77 6.68 5.47
35.0 4.75 2.96 5.37 3.37 5.66 3.88 6.06 4.36 6.48 4.77 6.68 5.47
40.0 3.93 2.03 4.44 2.31 4.68 2.66 5.02 2.99 5.36 3.27 5.53 3.75
46.0 3.11 1.27 3.52 1.45 3.71 1.67 3.97 1.87 4.25 2.05 4.38 2.35
NOTES:
• TC: Total Capacity (kW), SHC: Sensible Heat Capacity (kW)
• Values mentioned in the table are based on the following conditions:
– Pipe length: 5 m, Height difference: 0 m (Outdoor unit—Indoor unit)
 Medium static pressure duct type
Model: ARXG22KMLB
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 6.01 3.96 6.79 4.51 7.15 5.19 7.66 5.83 8.19 6.38 8.44 7.31
-5.0 6.01 3.96 6.79 4.51 7.15 5.19 7.66 5.83 8.19 6.38 8.44 7.31
0.0 6.01 3.96 6.79 4.51 7.15 5.19 7.66 5.83 8.19 6.38 8.44 7.31
5.0 6.01 3.96 6.79 4.51 7.15 5.19 7.66 5.83 8.19 6.38 8.44 7.31
10.0 6.01 3.96 6.79 4.51 7.15 5.19 7.66 5.83 8.19 6.38 8.44 7.31
15.0 6.01 3.96 6.79 4.51 7.15 5.19 7.66 5.83 8.19 6.38 8.44 7.31
20.0 6.01 3.96 6.79 4.51 7.15 5.19 7.66 5.83 8.19 6.38 8.44 7.31
25.0 6.01 3.96 6.79 4.51 7.15 5.19 7.66 5.83 8.19 6.38 8.44 7.31
30.0 6.01 3.96 6.79 4.51 7.15 5.19 7.66 5.83 8.19 6.38 8.44 7.31
35.0 6.01 3.96 6.79 4.51 7.15 5.19 7.66 5.83 8.19 6.38 8.44 7.31
40.0 4.97 2.71 5.62 3.09 5.92 3.56 6.34 4.00 6.78 4.37 6.99 5.01
46.0 3.94 1.70 4.45 1.94 4.69 2.23 5.02 2.51 5.37 2.74 5.53 3.14
Model: ARXH22KMTAP
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 6.01 4.32 6.79 4.91 7.15 5.66 7.66 6.35 8.19 6.95 8.44 7.97
-5.0 6.01 4.32 6.79 4.91 7.15 5.66 7.66 6.35 8.19 6.95 8.44 7.97
0.0 6.01 4.32 6.79 4.91 7.15 5.66 7.66 6.35 8.19 6.95 8.44 7.97
5.0 6.01 4.32 6.79 4.91 7.15 5.66 7.66 6.35 8.19 6.95 8.44 7.97
10.0 6.01 4.32 6.79 4.91 7.15 5.66 7.66 6.35 8.19 6.95 8.44 7.97
15.0 6.01 4.32 6.79 4.91 7.15 5.66 7.66 6.35 8.19 6.95 8.44 7.97
20.0 6.01 4.32 6.79 4.91 7.15 5.66 7.66 6.35 8.19 6.95 8.44 7.97
25.0 6.01 4.32 6.79 4.91 7.15 5.66 7.66 6.35 8.19 6.95 8.44 7.97
30.0 6.01 4.32 6.79 4.91 7.15 5.66 7.66 6.35 8.19 6.95 8.44 7.97
35.0 6.01 4.32 6.79 4.91 7.15 5.66 7.66 6.35 8.19 6.95 8.44 7.97
40.0 4.97 2.95 5.62 3.37 5.92 3.88 6.34 4.36 6.78 4.76 6.99 5.46
46.0 3.94 1.85 4.45 2.11 4.69 2.43 5.02 2.74 5.37 2.99 5.53 3.42
NOTES:
• TC: Total Capacity (kW), SHC: Sensible Heat Capacity (kW).
• Values mentioned in the table are based on the following conditions:
– Pipe length: 5 m, Height difference: 0 m (Outdoor unit—Indoor unit)
- 403 -
6-2. Cooling capacity
6. Capacity table
OUTDOOR UNIT AOYG30KBTA4
OUTDOOR UNIT
AOYG30KBTA4
