3) Ceiling height (for Compact cassette type only)
Select the appropriate ceiling height according to the place of installation.
Function number Setting value Setting description Factory setting
20
00 Standard ♦
01 High ceiling
For the specific height for each setting value, refer to “Installation space” in Chapter 2. "Dimensions"
in Chapter 1. GENERAL INFORMATION on page 01-14.
In case of cassette type models:
The ceiling height values are for the 4-way outlet. Do not change this setting in the 3-way outlet
mode.
7,000 or 9,000 Btu/h models cannot be installed in high ceilings.Do not change this setting.
4) Outlet directions (for Compact cassette type only)
Select the appropriate number of outlet directions according to the installation conditions.
Function number Setting value Setting description Factory setting
22
00 4-way ♦
01 3-way
1-5. Function details - (05-41) - 1. Function settings (for indoor unit)
FIELD
WORKING
FIELD
WORKING
