¢ Evaporator
42
Insulation Box Sub Assy (30,36,45,54)
Pipe cover
43 Wind Guide Board 9382125004
9378580664
41
Cabinet B sub assy
Cabinet A L
9381787005
Top plate assy
Evaporator holder
Ref. Description
Part number
Evaporator Total Assy (24)
42 9378580688Evaporator Total Assy (36,45,54)
41
42
43
Insulation Box Sub Assy (24)41
9381787012
42 9378580671Evaporator Total Assy (30)
3-1. Models: AUXG24KRLB, AUXG30KRLB, AUXG36KRLB, AUXG45KRLB, and
AUXG54KRLB
- (02-9) - 3. Indoor unit parts list
