Fujitsu AO G18KATA Series Service Manual

1. Specifications
1-1. Indoor unit
Type
Cassette
Inverter heat pump
Model name AUXG24KRLB AUXG30KRLB AUXG36KRLB
Power supply 230 V ~ 50 Hz
Power supply intake Outdoor unit
Available voltage range 198—264 V
Capacity
Cooling
Rated
kW 6.8 8.5 9.5
Btu/h 23,200 29,000 32,400
Min.—Max.
kW 0.9—7.4 2.8—9.6 2.8—10.6
Btu/h 3,100—25,200 9,600—32,700 9,600—36,100
Heating
Rated
kW 7.5 10.0 10.8
Btu/h 25,600 34,100 36,850
Min.—Max.
kW 0.9—8.6 2.7—10.8 2.7—12.5
Btu/h 3,100—29,300 9,200—36,800 9,200—42,600
Input power
Cooling
Rated
kW
2.12 2.56 3.06
Max. 2.60 3.53 4.19
Heating
Rated 1.97 2.64 2.58
Max. 2.58 4.17 4.48
Current
Cooling
Rated A
9.3 11.3 13.6
Heating 8.7 11.7 11.4
Power factor
Cooling
%
98.6 98.2 98.0
Heating 98.9 98.2 98.0
EER Cooling
kW/kW
3.21 3.32 3.10
COP Heating 3.81 3.79 4.19
Moisture removal L/h (pints/h) 2.7 (4.8) 2.5 (4.4) 3.3 (5.8)
Maximum operating current *1
Cooling
A
12.6 22.5
Heating 12.6 22.5
Fan
Airflow rate
Cooling
HIGH
m
3
/h
1,150 1,600 1,870
MED 1,050 1,400 1,560
LOW 980 1,270 1,410
QUIET 870 1,150 1,160
Heating
HIGH 1,150 1,600 1,870
MED 1,050 1,400 1,560
LOW 980 1,270 1,410
QUIET 870 1,150 1,160
Type × Q'ty Turbo fan × 1
Motor output W 81
Sound pressure level *2
Cooling
HIGH
dB (A)
35 40 44
MED 33 38 41
LOW 32 36 38
QUIET 29 33 34
Heating
HIGH 35 40 44
MED 33 38 41
LOW 32 36 38
QUIET 29 33 34
Heat exchanger type
Dimensions (H × W × D)
mm
Main1: 210 × 2,127 × 13.3
Main2: 210 × 2,061 × 13.3
Main1: 252 × 2,127 × 13.3
Main2: 252 × 2,061 × 13.3
Main1: 252 × 2,131 × 13.3
Main2: 252 × 2,064 × 13.3
Main3: 252 × 1,999 × 13.3
Fin pitch
Main1: 1.2
Main2: 1.2
Main1: 1.3
Main2: 1.3
Main3: 1.3
Rows × Stages
Main1: 1 × 10
Main2: 1 × 10
Main1: 1 × 12
Main2: 1 × 12
Main1: 1 × 12
Main2: 1 × 12
Main3: 1 × 12
Pipe type Copper tube
Fin type Aluminum
Dimensions
(H × W × D)
Net
mm
246 × 840 × 840 288 × 840 × 840
Gross 298 × 960 × 950 340 × 960 × 950
Weight
Net
kg
24 26 29
Gross 29 32 34
Connection pipe
Size
Liquid
mm (in)
Ø 6.35 (Ø 1/4) Ø 9.52 (Ø 3/8)
Gas Ø 12.70 (Ø 1/2) Ø 15.88 (Ø 5/8)
Method Flare
Drain hose
Material PVC
Size mm Ø 25 (I.D.), Ø 32 (O.D.)
Operation range
Cooling
°C 18 to 32
%RH 80 or less
Heating °C 16 to 30
Cassette grille
(Option)
Model name
UTG-UKYC-W
Material Polystyrene
Color
White
Approximate color of Munsell N 9.25/
Dimensions
(H × W × D)
Net
mm
53 × 950 × 950
Gross 110 × 1,000 × 1,010
Weight
Net
kg
6.0
Gross 10.0
Remote control (Option)
Wired remote controller, Wireless remote controller, Mobile app*3 (FGLair
™
)
1-1. Indoor unit - (01-1) - 1. Specifications
