5-2. Outdoor unit
¢
Model: AOYG24KATA
Part name Exterior Q’ty Part name Exterior Q’ty
Installation manual 1 Drain pipe 1
¢
Models: AOYG30KATA, AOYG36KATA, AOYG45KATA, and
AOYG54KATA
Part name Exterior Q’ty Part name Exterior Q’ty
Installation manual 1 Drain cap 3
Drain pipe 1 One-touch bush 2
5-2. Outdoor unit - (02-23) - 5. Accessories
