Item no. Part no. Part name Service part
1 9383880001 Top panel assy ♦
2 9381013005 Protective net ♦
3 9375361013 Net rubber ♦
4 9900984038 Thermistor (Heat exchanger) ♦
5 9900727154 Thermistor assy ♦
6 9383607004 Thermo holder ♦
7 9383874017 Right panel sub assy ♦
8 9383879005 Rear pipe cover ♦
9
9711233028 Inverter PCB (for 45 model) ♦
9711233011 Inverter PCB (for 54 model) ♦
10 9900203061 Terminal ♦
11
9711431066 Main PCB (Service) (for 45 model) ♦
9711431158 Main PCB (Service) (for 54 model) ♦
12 313166024302 Drain cap ♦
13 9303029015 Drain assy ♦
14 9383871009 Base assy ♦
15 9383876011 Service panel sub assy ♦
16 9383878008 Front pipe cover ♦
17 9351355005 Emblem rear ♦
18 9383863011 Front panel assy ♦
19 9383604003 Blow grille ♦
20 9383689000 Blow grille insulation ♦
21 9383882012 Left panel sub assy ♦
22 9383336003 Propeller fan ♦
23 9603733018 Brushless motor ♦
24 9383862021 Motor bracket assy ♦
25 9374420636 Condenser sub assy ♦
a — Separate wall assy —
b — Control box unit —
4-3. Models: AOYG45KATA and AOYG54KATA - (02-19) - 4. Outdoor unit parts list
