Item no. Part no. Part name Service part
50 9383858017 Sound insulation unit ♦
51 9900565091 Thermistor (Outdoor temp.) ♦
52 9900186029 Pressure switch ♦
53
9374425662 4-way valve assy (for 45 model) ♦
9374425655 4-way valve assy (for 54 model) ♦
54 9970194016 Solenoid ♦
56 9375250157 Accumulator assy ♦
57 9970209000 Expansion valve coil ♦
58 9370947311 Expansion valve assy ♦
59 9379079013 3-way valve assy ♦
60 9377958037 3-way valve assy ♦
61 9900985028 Thermistor (Compressor) ♦
62
9383851032 Compressor (for 45 model) ♦
9383851018 Compressor (for 54 model) ♦
63 9379179058 Rubber washer D ♦
64 9377973016 Special nut ♦
a — Thermistor spring —
b — Joint pipe D —
c — Accumulator holder A —
d — Wiring fixation unit —
4-3. Models: AOYG45KATA and AOYG54KATA - (02-21) - 4. Outdoor unit parts list
