10. Electrical characteristics
Model name AOYG18KATA AOYG22KATA AOYG24KATA
Power
supply
Voltage V 230 ~
Frequency Hz 50
Max operating current *1 A 10.1 11.6 12.6
Starting current A 7.6 8.8 9.7
Wiring
spec.
*2
Circuit breaker current A 13 16 20
Power cable
mm
2
1.5
Connection
cable *3
Cross-sectional area
mm
2
1.5
Limited wiring length m 21 26
Model name AOYG30KATA AOYG36KATA AOYG45KATA
Power
supply
Voltage V 230 ~
Frequency Hz 50
Max operating current *1 A 22.5 28.1
Starting current A 12.6 13.8 21.3
Wiring
spec.
*2
Circuit breaker current A 25 32
Power cable
mm
2
4.0
Connection
cable *3
Cross-sectional area
mm
2
1.5
Limited wiring length m 31
*1: Maximum current is the total current of the indoor unit and the outdoor unit.
*2: Selected sample based on Japan Electrotechnical Standards and Codes Committee E0005. As
the regulations of wire size and circuit breaker differ in each country or region, select appropriate de-
vices complied to the regional standard.
*3: Limit voltage drop to less than 2%. Increase conductor size if voltage drop is 2% or more.
