Fujitsu AO G24LBCB Series Service Manual

MEASUREMENT
DIMENSIONS
WEIGHT
POWER SOURCE
FAN MOTOR
DISCRIMINATION
High
FAN SPEED
Medium
Low
INDOOR UNIT
DUCT
INDOOR UNIT
ARYG18LLTB ARYG22LMLA ARYG24LMLA
H x W x D 270 x 1,135 x 700 mm198 x 900 x 620 mm
Shipping / Net 44 kg / 38 kg30 kg / 23 kg
AIRCIRCULATION HIGH 1,100 m3/h
940 m3/h
400 V, 50 Hz, 3 phase, 4 W
1,380 r.p.m.
1,300 r.p.m.
1,220 r.p.m.
MFG-24RVA
MFG-24WVA
830 r.p.m.
700 r.p.m.
600 r.p.m.
Quiet
1,140 r.p.m. 550 r.p.m.
ELECTRICAL DATA
2014.06.19 4
