INDOOR UNIT
CEILING
ABYG18LVTB
ABYG22LVTA
ABYG24LVTA
49
23 Indicator PCB Assy 9705798090
21
22 Side Cover R Assy 9359069102
Panel 9358531259
Ref. Description Part number
2012.04.24
24 Air Filter 9358567029
26 Arm Bracket 9359281009
27 Grille Support 9358602003
28 Filter Bracket 9358607008
25 Grill F 9358532027
21
22
23
27
28
27
24
25
24
26
