Fujitsu AO G36KBTB Series Service Manual

3. Dimensions
3-1. Compact cassette type
¢
Models: AUXG18KVLA, AUXG22KVLA, and AUXG24KVLA
Unit: mm
285 285
Ceiling
114
B
View A
570: Indoor unit
370
540
Hanging bolt position
a: Ceiling openings
530
530
Hanging bolt position
Drain hose
A
215
19
30
123
30
262
183
Control Box
146
40
C
620
620
IR receiver
Grid type grille
View B
View C
114
a: Ceiling openings
Cassette grille (Option [Grid type]) mm 580 to 610
3-1. Compact cassette type - (01-8) - 3. Dimensions
