2-3. E: 12. Wired remote controller communication error (Indoor
unit)
Indicator
Wired remote
controller
Error code E: 12
Detective actuator
Indoor unit Main PCB When the indoor unit cannot receive the signal from
wired remote controller more than following time during
normal operation.
• 3-wire type: 1 minute
• 2-wire type: 2.5 minutes
Wired remote control
Forecast of cause
Terminal connection abnormal
Wired remote control failure
Main PCB failure
Check point 1. Check the connection of terminal
After turning off the power, check & correct the followings.
• Check the connection of terminal between wired remote controller and indoor unit, and check if
there is a disconnection of the cable.
↓
Check Point 1-2 : Check Wired remote controller and main PCB
[AU type]
Check voltage at CN14 of main PCB (terminal 1—3, terminal 1—2). (Power supply to the remote
controller)
• If it is DC 12 V, remote controller is failure. (Main PCB is normal)
– Replace remote control
• If it is DC 0 V, main PCB is failure. (Check remote controller once again)
– Replace main PCB
[AR type]
Check voltage at CN300 of main PCB (terminal 1—3, terminal 1—2). (Power supply to the remote
controller)
• If it is DC 13 V, remote controller is failure. (Main PCB is normal)
– Replace remote control
• If it is DC 0 V, main PCB is failure. (Check remote controller once again)
– Replace main PCB
↓
End
2-3. E: 12. Wired remote controller communication error (Indoor unit) - (03-9) - 2. Troubleshooting with error code
