¢ Louvers and motors
Parts No.DescriptionRef
21
22
23
24
Step Motor (White connector)
Step Motor (Red connector)
Flap assy A
Flap assy B
9900139070
9900139087
9375727048
9377759047
21
22
23
24
2-1. Model: UTG-UFGF-W - (02-4) - 2. Cassette grille (optional part) parts list
