Fujitsu AO G36KBTB Series Service Manual

¢
Duct type

Models: ARXG22KMLA and ARXG24KMLA
Part name Exterior Q’ty Part name Exterior Q’ty
Operating manual 1 Cable tie (Small) 1
Installation manual 1 Cable tie 1
CD-ROM 1
Coupler heat insulation
(Large)
1
Hanger 4
Coupler heat insulation
(Small)
1
Drain hose insulation 1
M10 nut A
(with flange)
4
Cable tie (Large) 1
M10 nut B
(with spring lock
washer)
4
5-2. Outdoor unit
¢
Models: AOHG36KRTA, AOHG45KRTA, and AOHG54KRTA
Part name Exterior Q’ty Part name Exterior Q’ty
Installation manual 1 Drain cap 3
Drain pipe 1 One-touch bush 2
5-1. Indoor unit - (02-28) - 5. Accessories
TECHNICAL DATA AND PARTS LIST TECHNICAL DATA AND PARTS LIST

Fujitsu AO G36KBTB Series Specifications
