Fujitsu AOTG54LCTL Service Manual

H x W x DOUTDOOR UNIT
DIMENSIONS
Shipping / NetOUTDOOR UNIT
WEIGHT
POWER SOURCE
Cooling
RUNNING
CURRENT
Heating
INPUT WATTS
Cooling
Heating
E.E.R.
C.O.P.
Cooling
Heating
Cooling
Heating
MOISTURE REMOVAL
AIRCIRCULATION
OUTDOOR
FAN MOTOR
INDOOR UNIT, Discrimination
High
INDOOR UNIT
Fan 1 / Fan 2
Medium
Low
Upper fan
Lower fan
OUTDOOR UNIT, Discrimination
OUTDOOR UNIT
Cooling
OUTDOOR UNIT
Heating
TYPE
Cooling & Heating
INDOOR UNIT
ARTG54LHTC
OUTDOOR UNIT AOTG54LCTL
COOLING CAPACITY
HEATING CAPACITY
INDOOR UNIT H x W x D 425 x 1,250 x 490 mm
1,290 x 900 x 330 mm
INDOOR UNIT
Shipping / Net
61 kg / 54 kg
101 kg / 93 kg
18.4 A
18.3 A
4.40 kW
4.37 kW
3.18 kW/kW
3.66 kW/kW
1.5 L/hr
6,850 m3/h
MAXIMUM CURRENT 23.5 A
AIRCIRCULATION INDOOR
3,550 m3/h
6,900 m3/h
240 V, 50 Hz, single phase
1,090 r.p.m. / 1,050 r.p.m.
900 r.p.m. / 860 r.p.m.
780 r.p.m. / 740 r.p.m.
MFG-54AVN
MFE-45VVT
830 r.p.m.
900 r.p.m.
Lower fan 800 r.p.m.
Upper fan
850 r.p.m.
14.0 kW
16.0 kW
ELECTRICAL DATA
TYPE
DISCRIMINATION
WEIGHT (with oil)
REFRIGERANT TYPE R410A
Hermetic type, Inverter,
4 poles, 3 phase,
DC motor, Twin Rotary
DA422A3F-28ZAD
23.0 kg
PRECHARGED REFRIGERANT 3,450 g
COMPRESSOR AND REFRIGERANT
2012.10.22 1
SPECIFICATIONS
MAX PIPE HEIGHT
30 m
Pipe length
30 m 3,450 g
FULL CHARGE
45 m 4,200 g
60 m 4,950 g
75 m 5,700 g
ADDITIONAL CHARGE
50 g/m
NOISE LEVEL
High
45 dB
INDOOR UNIT
Medium 40 dB
Low
Cooling
Heating
36 dB
OUTDOOR UNIT
55 dB
57 dB
