En-8
MASTER
CONTROL
SET
TEMP.
SET
TIME
FAN
CONTROL
LOW HIGH
MASTER
CONTROL
SET
TEMP.
SET
TIME
FAN
CONTROL
AUTO
OPERATION
The operating mode and standard thermostat settings are selected automatically when operation begins.
¶ When automatic operation is initiated, the fan will run at very low speed for about one minute while the unit
detects and selects the proper operating mode.
¶ Once the operating mode has been set, the mode will not change even if the room temperature changes.
However, during the monitor operation mode, if the room temperature changes to below 72°F, the mode will
automatically switch to Heat, and when it rises above 75°F the mode will automatically switch to Dry.
¶ When in the monitor mode, the fan will operate very slowly.
¶ If the START/STOP button is pressed to recommence operation within two hours after stopping automatic
operation, the unit will begin operating from the same mode as before.
Heating: ¶ Use to warm your room.
¶ When Heating mode is selected, the air conditioner will operate at very low fan speed for about 3 to 5 minutes,
after which it will switch to the selected fan setting. This period of time is provided to allow the indoor unit to
warm up before begin full operation.
¶ When the room temperature is very low, frost may form on the outside unit, and its performance may be
reduced. In order to remove such frost, the unit will automatically enter the defrost cycle from time to time.
During Automatic Defrosting operation, the OPERATION indicator Lamp (red) will flash, and the heat operation
will be interrupted.
Cooling: ¶ Use to cool your room.
Dry: ¶ Use for gently cooling while dehumidifying your room.
¶ You cannot heat the room during Dry mode.
¶ During Dry mode, the unit will operate at low speed; in order to adjust room humidity, the indoor unit’s fan may
stop from time to time. Also, the fan may operate at very low speed when detecting room humidity.
¶ The fan speed cannot be changed manually when Dry mode has been selected.
Fan: ¶ Use to circulate the air throughout your room.
Press the MASTER CONTROL button to select AUTO.
The operating mode “AUTO” will appear alone in the display. The transmit indica-
tor will flash to indicate the command has been sent, and about three seconds
later the entire display panel will reappear.
To Set the Thermostat
Press the TEMPERATURE set button.
About three seconds later, the entire display will reappear.
NOTE: The thermostat setting should be considered a standard value, and may
differ somewhat from the actual room temperature.
When set to
4°F lower
When set to
2°F lower
When set to
“normal”
When set to
2°F higher
When set to
4°F higher
LOW HIGH LOW HIGH LOW HIGH LOW HIGH LOW HIGH
Actual Room Operating Mode Thermostat Setting
Temperature (“normal” setting)
88°F or above = Cooling = 82°F
82°F-88°F = Cooling = 80°F
76°F-82°F = Dry = 76°F
72°F-76°F = Monitor
Below 72°F = Heating = 74°F
AUTO: ¶ Depending on the room temperature at the time operation begins,
the operating mode will be switched automatically as shown in the
accompanying table.
Also, depending on the operating mode, the room temperature set-
ting will cause the “standard” temperature to be set as shown.
During Heating mode:
Set the thermostat to a temperature set-
ting that is higher than the current room
temperature. The Heating mode will not
operate if the thermostat is set lower
than the actual room temperature.
During Cooling/Dry mode:
Set the thermostat to a temperature set-
ting that is lower than the current room
temperature. The Cooling and Dry
modes will not operate if the thermo-
stat is set higher than the actual room
temperature (in Cooling mode, the fan
alone will operate).
During Fan mode:
You can not use the unit to heat and
cool your room.
Example: When set to “normal”.
To Select Automatic Operation
To Stop Operation
Press the START/STOP button.
The OPERATION indicator lamp (red) (Fig. 3 5) will go out.
About Mode Operation
