En-7
SLEEP TIMER
MASTER
CONTROL
SET
TEMP.
SET
TIME
FAN
CONTROL
START/STOP
COOL
SLEEP TIMER
MASTER
CONTROL
SET
TEMP.
SET
TIME
FAN
CONTROL
AUTO
SLEEP TIMER
MASTER
CONTROL
SET
TEMP.
SET
TIME
FAN
CONTROL
START/STOP
F
To Set the Fan Speed
Press the FAN CONTROL button (Fig. 6 +).
Each time the button is pressed, the fan speed changes in the following order:
About three seconds later, the entire display will reappear.
When set to AUTO:
Heating: Fan operates so as to optimally circulate warmed air.
However, the fan will operate at very low speed when the temperature of
the air issued from the indoor unit is low.
Cooling: As the room temperature approaches that of the thermostat setting, the
fan speed becomes slower.
Fan: The fan alternately turns on and off; when on, the fan runs at the low fan
speed.
The fan will operate at very low setting during Monitor operation and at
the start of the Heating mode.
When set to QUIET:
SUPER QUIET operation begins. The indoor unit's airflow will be reduced for quieter
operation.
÷ SUPER QUIET operation cannot be used during Dry mode. (The same is true
when Dry mode is selected during AUTO mode operation.)
÷ During SUPER QUIET operation, Heating and Cooling performance will be reduced
somewhat.
OPERATION
To Select Mode Operation
Press the START/STOP button (Fig. 6 ¡).
The Indoor Unit’s OPERATION Indicator Lamp (red) (Fig.3 5) will light.
The air conditioner will start operation.
Press the MASTER CONTROL button (Fig.6 *) to select
the desired mode.
Each time the button is pressed, the mode will change in the following order.
1
Example: When set to COOL
2
About three seconds later, the entire display will reappear.
Example: When set to 80°F.
Example: When set to AUTO.
The thermostat setting should be considered a standard value, and may differ
somewhat from the actual room temperature.
AUTO HIGH MED LOW
QUIET
AUTO COOL DRY
FAN
HEAT
In order to increase the drying effect
during quiet cooling operation, the fan
of the indoor unit may stop.
To Set the Thermostat
Press the TEMPERATURE set button.
button: Press to increase the thermostat setting.
button: Press to lower the thermostat setting.
Thermostat setting range:
Heating ................................................................. 60°F to 88°F
Cooling/Drying ..................................................... 64°F to 88°F
About three seconds later, the entire display will reappear.
NOTE:
The thermostat setting should be considered a standard value, and may differ
somewhat from the actual room temperature.
During Fan mode, set the unit to “– –” for continuous fan operation regardless
of room temperature.
