REFRIGERANT
SYSTEM DIAGRAM
Refrigerant direction
Cooling
Heating
Refrigerant pipe diameter
Liquid : 1/4" (6.35 mm)
Gas : 3/8" (9.52 mm)
2-Way valve
Strainer
Strainer
3-Way valve
Muffler
4-Way valve
Expansion valve
Heat exchanger
(indoor unit)
Heat exchanger
(outdoor unit)
Compressor
2012.07.19
4
4
6
Table of Contents
Table of Contents
1
Cassette Type
1
Indoor Unit
1
Specifications
2
Dimensions
3
Refrigerant System Diagram
5
Circuit Diagram
6
Indoor Pcb Circuit Diagram
7
Outdoor Pcb Circuit Diagram
11
Error Detection
13
Parts (Decoration Panel)
15
Parts (Indoor Unit)
17
Parts (Outdoor Unit)
20
Accessories
23
