DIMENSIONS
11-5/8 inch
295 mm
10-5/8 inch
270 mm
37 inch
940 mm
2014.12.16 2
INDOOR UNIT
15.8 to 16.7 mm
Drain hose
Diameter
Outside
Inside :
13.8 mm
600 mm
OUTDOOR UNIT
11-13/32 inch
290 mm
31-3/32 inch
790 mm
21-1/4 inch
540 mm
24-13/32 inch
620 mm
