43
49
48
44
42
41
46
47
45
INDOOR UNIT
Control box
18
46
Terminal 9900638016
Controller PCB Assy 9708713229
45
Earth Terminal 9318918007
41
Control Box
9318916003
42
Cover Shield A
9318882018
43 Box Shield Assy 9319344003
44
49 Step Motor 9900384166
47
Room Thermistor Holder
9319068008
48 Gear Cover 9318902006
Ref. Description Part number
56
Display PCB Assy 970882401757
-- Thermistor Assy 9900627003
Display Assy 9708823010
54 Grille Key Top 9319334004
55 Micro Switch 9900625009
51 Panel Gear 9319293004
Switch Case 9319332000
52
53
Gear Case 9318903003
50 Gear B 9319294001
Ref. Description Part number
2012.01.05
52
53
50
51
54
55
56
57
To Next Page
