– 17 –
AOU18RD
Ref.
No.
Description
Ord.
Q’ty
Part No.
Ref.
No.
Description
Ord.
Q’ty
Part No.
OUTDOOR UNIT
2 Fan Cover 9363678000
4 Emblem Rear 9351355005
5 Cabinet-A, Painted 9303876015
6 Cabinet-C, Painted 9352674006
7 Panel (Top) 9357971018
9 Cabinet-B, Painted 9353629012
10 Noise Insulation-E 313791106305
12 Base Assy, Painted 9352577017
13 3-Way Valve 9357968001
14 2-Way Valve 9357969008
16 Condenser Assy 9366566007
29 Separate Wall 313111033209
32 -7 Control Box Metal-U 9365924006
32 -8 Control Box Metal-S 9365925003
34 Capacitor (Fan Motor) 9355306010
37 Running Capacitor 9356386035
38 Capacitor Band 9352123009
39 Propeller Fan Assy 9300855013
41 Fan Motor Assy-Out 9600738139
45 Motor Fixing Table Assy 313029311100
46 Compressor Assy 9366567004
51 Special Nut 9359430018
55 Special Nut M8 313252257701
67 Rubber 313659068604
107 Rubber Seat-A 9359425014
109 Terminal Cover 9363263008
158 Connect Pipe A1 9366570004
158-1 Connect Pipe B1 9366576006
184-1 Thermo Spring-A 313728262708
187 Clamp No.1219 313361271706
210 Main Relay 9356581007
213 Noise Insulation-B 9352670008
230-1 Amt (OLP Assy) 9366568001
233 Transformer 9704034014
234 Thermistor Assy 9702925017
236 Controller PCB Assy 9704088017
272 Strainer Assy 9366602019
327 Suction Pipe-A Assy 9366572008
327-1 Suction Pipe-B Assy 9366578000
338 Motor Fixture 313029297108
343-1 Solenoid Coil 9704046024
343-2 Solenoid Coil 9704046017
344 4-Way Valve 313947302811
352-1 Expansion Coil-A 9366562016
352-2 Expansion Coil-B 9366563013
363 Bracket (Compressor) 9363840001
365 Bracket (3-Way Valve) 9355842020
381-2 Locking Spacer KGLS-8S 0600035020
381-3 Locking Spacer KGPS-8S 0600118051
412 Terminal Gasket 9362004008
423 Noise Insulation-F 9350944019
425 Earth Terminal 9355678001
450-3 Discharge Pipe-B Assy 9366577003
450 Discharge Pipe-A Assy 9366571001
635 Terminal Washer 9359428015
678 Bracket (Thermistor) 313557406106
717 Center Plate 9363776003
815 Terminal 8P 9358659021
815-4 Terminal 2P 9701971015
823 Fuse Holder 0500802111
824 Fuse 3A-250V 0600106546
825-1 Expansion Valve-A Assy 9360821034
825-2 Expansion Valve-B Assy 9360822031
827 Capillary-A Assy 9360814081
828 Capillary-B Assy 9360815088
838-1 Inlet Pipe (Cond.)-A 9360832023
838-2 Inlet Pipe A1 9366569008
840-1 Inlet Pipe (Cond.)-B 9360833020
840-2 Inlet Pipe B1 9366575009
940 Hole Plug No.0875 9355891004
941 Conduit Plate 9359468011
When you order parts, please make a photocopy of this page
and fill the number of the parts in the “Order” column.
To Next Page
