– 18 –
When you order parts, please make a photocopy of this page
and fill the number of the parts in the “Order” column.
Ref. No. Ref. No.Description Description
Ord.
Q’ty
Ord.
Q’ty
IC1 IC MB89625RPFM-1049 9702928018
IC2 IC PST600CMT 0101461120
IC3 IC NJM7805FA 0100462081
IC4 IC S-93C46ADFJ-TB 0101919027
IC5,6 IC MC1413D 0101736013
Q1~3 Xstr DTC124EKA 0000936033
D1 Diode DAN202K 0000684019
D2 Diode D1F60 0000208024
C1,2,4~16,19,35
Cap. Ceramic 25V 0.1µF 0301102885
C21,22 Cap. Ceramic 50V 0.01µF 0301102830
C23~27 Cap. Ceramic 50V 1000pF 0300277096
C28~31 Cap. Elec. 25V 10µF 0300328026
C32 Cap. Elec. 16V 100µF 0301192251
C33 Cap. Elec. 25V 330µF 0301196952
C36 Cap. Ceramic 50V 0.01µF 0301102809
R1~6,8~11,14, Res. 10kΩ±10% 0201011010
15,27,31~39
R7 Res. 1/10W 10kΩ±1% 0200279497
R16~18,20 Res. 1kΩ±5% 0201010747
R21 Res. 1/10W 49.9kΩ±1% 0200279824
R22 Res. 1/4W 750Ω±5% 0200230719
R23,24 Res. 1/4W 560Ω±5% 0200230689
R25 Res. 1/10W 1kΩ±5% 0200212746
R26 Res. 47kΩ±5% 0201010426
R40 Res. 390Ω±5% 0201010648
JM1~6 Res. 0Ω 0200230016
JM7,8 Jumper Wire IPS-3043-02 1903332014
X1 Ceramic Resonator 0400061021
CST8.38MTW-TF01
BZ1 Buzzer PKM13EPY-4000-TF01 9701298013
CN1 Plug, PCB B3P-VH-B 0500011520
CN2 Plug, PCB 53324-1010 0501052096
CN3 Plug, PCB B5P-SHF-1AA 0500006069
CN4 Thermistor 105-503-96063 9702039028
CN5 Thermistor 105-103-86119 9700801078
CN6 Wire w/Connector 9703353017
UL1061AWG26 L=170
CN7 Plug, PCB B09B-PASK-1 0501360092
Part No. Part No.
INDOOR PCB
CONTROLLER PCB ASSEMBLY (Ref. No. 236)
Ref. No. Ref. No.Description Description
Ord.
Q’ty
Ord.
Q’ty
IC105 IC MIP0222SY-LT 0101972077
IC106 IC GK-30430 1082951006
D101 Diode D3SB60 0000689045
D102 Diode 1NH42 0000325028
D103 Diode D1FL20U 0000746519
D104 Diode D2FL20U 0000906500
D105 Diode D1F60U 0000208024
C101,102 Cap. Plastic 0.1µF 0300304075
C103,104,110 Cap. Ceramic 0.01µF 0300031063
C105 Cap. Elec. 450V 100µF 0300256060
C106 Cap. Plastic 0.01µF 0300334010
C107 Cap. Elec. 016V 47µF 0301197447
C108,111 Cap. Ceramic. 050V 0.1µF 0300311752
C109 Cap. Elec. 025V 330µF 0301196952
R101 Res. Cement 3.3Ω±5% 0200153148
R102 Res. Metal 100kΩ±5% 0201107690
R103 Res. 220Ω±5% 0200230344
R105 Res. Metal 1kΩ±5% 0200731742
SSR101 Relay G3MC-201PL-VD 9702430016
VA101~103 Varistor TNR10V471K 0000361224
SA101 Surge Absorber RAM-362LAS 0600275037
F101 Fuse MT3 3A-250V 0600239015
F102 Fuse 1A-250V 0600078119
T101 Switching Transformer 1302433015
ETS28AS138AG
L101 EMI Filter ELF15N011A 0400165095
SW101 Push Switch KSM0632B 9703476013
CN101 Plug, PCB B3P5-VH-B 0500011735
CN102 Plug, PCB 53406-9910 0500951048
CN103 Plug, PCB B2P3-VH-B-R 0500011766
CN104 Wire w/Connector 9703350016
UL1061 AWG26 L=200
W101 Wire w/Terminal 1302453013
UL1015 AWG18 WHT L=150
W104 Wire w/Terminal 9703348037
UL1015 AWG18 GRN L=130
W105 Wire w/Terminal RED L=150 1302454010
W106 Wire w/Terminal BLK L=150 9703348044
JP101,102 Wire 1301974038
UL1015 AWG22 YEL/ORG L=200
Part No. Part No.
INDOOR PCB
POWER SUPPLY PCB ASSEMBLY (Ref. No. 875)
Ref. No. Ref. No.Description Description
Ord.
Q’ty
Ord.
Q’ty
IC201 Remote Control Amplifier 0101525129
SBX1810-22
D201 Diode SLR-325VC RED 0000813259
D202 Diode SLR-325MC GRN 0000813242
D203 Diode SLR-325DC ORG 0000813235
C201 Cap. Ceramic 25V 0.1µF 0301102885
C202 Cap Elec. 25V 10µF 0300099339
Part No. Part No.
INDOOR PCB
INDICATOR PCB ASSEMBLY (Ref. No. 385)
ASU9RD
To Next Page
